Autel Robotics EVO II 640T V3
The Most Compact and Advanced Thermal Drone
A modern option for airborne exploration and thermal imaging is the Autel Robotics EVO II Dual 640T V2 Thermal Drone Camera Rugged Bundle. The sophisticated EVO II Dual 640T V2 drone, which is included in this bundle, has a high-resolution thermal camera for spotting heat signatures. The tough bundle offers portability and durability, making it ideal for industrial applications, search and rescue missions, and more. This drone’s remarkable thermal imaging capabilities make it a trustworthy tool for experts who need accurate and thorough thermal data. The Autel Robotics EVO II Dual 640T V2 Thermal Drone Camera Rugged Bundle lets you discover new areas of the world and get vital thermal insights.
Autel Robotics’ new generation thermal camera
Maximum efficiency in all viewing conditions
EVO II Dual supports up to 10 thermal palettes to cope with a variety of complex shooting environment and mission scenarios.
The thermal image is integrated into the standard RGB image at the same time. This allows the user to obtain both visual and thermal data at the same time and allows for easier positioning and subject tracking.
8K allows even the smallest detail to be captured and preserved
8K Video, unmatched clarity
Autel Evo II Dual records in resolutions up to 7680×4320. With 4 times as many pixels compared to 4k (and 16 times compared to HD), 8k videos redefine image clarity and depth.
The Evo II Dual’s 48MP Sensor captures every forensic-relevant detail to assist in precise evidence capture. Both thermal and RGB images are provided with embedded Metadata making the EVOII Dual the ultimate Public Safety tool.
4X Lossless zoom
The high resolution provides the ability to zoom deep into a scene and crop an image or video to 4k without any loss in quality. Capture a scene, zoom in, and reframe your shots with ease.
4K HDR for greater dynamic range
4K HDR offers greater detail in highlights and shadows, providing higher-quality images from the most demanding environments.
360° Obstacle Avoidance
Equipped with 19 groups of sensors including 12 visual sensors, the main camera, ultrasound, IMUs, and other sensors enable the building of three-dimensional maps and path planning in real-time.
EVO II Dual 640T V3
See incredible detail in dark environments from up to 450+ feet with the EVO II Dual 640T V3 FLIR Boson 640 thermal sensor. Combine your thermal capabilities with the Dual’s 8K/48MP visual camera and see the power of aerial intelligence. 12 visual sensors provide omnidirectional obstacle avoidance and with no geofencing, you’ll never have to worry about being grounded when operations are mission-critical.
Multiple Temperature Measurement Modes, Professional Analysis Tool
Central Temperature Measurement | Spot Temperature Measurement | Regional Temperature Measurement
Central temperature measurement: View a real-time display of the temperature in the center area of the screen.
Spot temperature measurement: Tap the screen, and the temperature of the selected object will be displayed in real-time.
Regional temperature measurement: Get a dynamic view of the average temperature, maximum temperature, and minimum temperature displayed in a selected area.
Powerful Infrared Thermal Analysis Tool
Temperature Alarm | Isotherm | Image Enhancement
Autel IR PC Tool: This free temperature measurement analysis tool is developed for the 640T V3, and enables users to quickly import images, edit and analyze temperature measurements, and to generate detailed reports for sharing and collaboration.
Temperature alarm: Monitors the screen temperature in real time. The system prompts the user when the temperature reaches a set threshold.
Isotherm: Set a temperature range and the system will detect any objects within the temperature range specified.
Image enhancement: Supports real-time adjustment of image brightness, contrast, and image details. The system will highlight any objects within the temperature target.
- 1x EVO II Dual 640T aircraft
- 1x EVO II Battery Charging Hub
- 1x EVO II 12V Car Charger
- 1x EVO II Hard Case
- 3x EVO II Aircraft Batteries
- 3x EVO II propeller (pairs)
- 1x EVO II Remote Controller
- 1x AC Charger
- 1x 12″ Cable USB Micro A – USB Type C
- 1x 12″ Cable USB Micro A – USB Micro B
- 1x Gimbal Cover
- 1x Limited 1-Year Autel Warranty
|Maximum Takeoff Weight||4.4 lb / 2000 g|
|Maximum Horizontal Speed||44.7 mph / 20 m/s|
|Maximum Ascent Speed||17.9 mph / 8 m/s|
|Maximum Descent Speed||8.9 mph / 4 m/s|
|Flight Ceiling||4.3 Miles / 7000 m|
|Maximum Flight Time||38 Minutes|
|Maximum Hover Time||33 Minutes|
|Maximum Tilt Angle||33°|
|Hovering Accuracy||±4.9′ / 1.5 m Horizontal with GPS
±1.0′ / 0.3 m Horizontal with Vision Positioning
±1.6′ / 0.5 m Vertical with GPS
±0.3′ / 0.1 m Vertical with Vision Positioning
|Maximum Angular Velocity||120°/s (Pitch)|
|Sensor Type||1/2″-Type CMOS Sensor|
|Sensor Resolution||Effective: 48 Megapixel|
|Focal Length||25.6mm (35mm Equivalent)|
|Field of View||79°|
100 to 6400
100 to 64,000
|Shutter Speed||1/8000 to 8 Seconds|
|Video Format||3840 x 2160p at 24/25/30/48/50/60 fps (120 Mb/s MOV/MP4)
2720 x 1528p at 24/25/30/48/50/60 fps (120 Mb/s MOV/MP4)
1920 x 1080p at 24/25/30/48/50/60 fps (120 Mb/s MOV/MP4)
|Still Image Support||DNG / JPEG
(8192 x 6144)
(4096 x 3072)
(3840 x 2160)
|Internal Storage||8 GB|
|Media/Memory Card Slot||Single Slot: microSD/microSDHC/microSDXC (UHS-III)|
|Photo Modes||Auto-Exposure Bracketing (AEB), Burst Shooting, Interval, Single Shot|
|Thermal||Sensor: Uncooled VOx Microbolometer
Lens: FOV H33° V26°, Focal 13mm
Sensor: 640 x 512
Pixel Size: 12 μm
Wavelength Range: 8-14 μm
Temp. Range: (High Gain) -20 to +150°, (Low Gain) 0 to +550°
Temp. Accuracy: ±3℃ or ±3% of Reading (Whichever is Greater) at Environmental Temp. -4 to 140°F / -20 to 60°C
Accurate Temp. Distance: 6.6 to 66′ / 2 to 20 m
Video Resolution/Format: 640 x 512 at 30 fps (MOV, MP4 (H.264/H.265)
Camera Resolution: (Infrared 640 x 512 / Picture-in-Picture 1920 x 1080, 1280 x 720)
Photo Mode: Single / Burst (3/5 Frames with 3 as Default) / Time-Lapse (JPG at 2/5/7/10/20/30/60 Seconds)
Photo Format: JPG (with IRG File)
|Number of Axes||3 (Pitch, Roll, Yaw)|
|Control Range||Pitch: -90 to 30°
Yaw: -90 to 90°
|Angular Speed||Pitch: 300°/s|
|GNSS Support||GPS, GLONASS, BeiDou, Galileo|
|Operating Range||Not Specified by Manufacturer|
|Required Object Reflectivity||>20%|
|Vision System||Downward, Forward, Backward, Left, Right|
|Obstacle Sensory Range||1.6 to 59.1′ / 0.5 to 18.0 m|
|Forward Field of View||60° (Horizontal)
|Downward Field of View||80° (Front to Back)
100° (Side to Side)
|Backward Field of View||60° (Horizontal)
|Operating Environment||Surface with Clear Patterns at >15 lux|
|Operating Frequency||0.9 GHz (902.000 to 928.000)
2.4 GHz (2.400 to 2.483)
5.8 GHz (5.725 to 5.850)
|Maximum Operating Distance||9.3 Miles / 15 km|
|Transmitter Power||20 dBm (2.4 G)
14 dBm (5.8 G)
20 dBm (2.4 G)
33 dBm (5.8 G)
|Battery Capacity||5800 mAh|
|Mobile App Compatible||No
*As of January, 2023: Check with manufacturer for the most up-to-date compatibility
|Built-In Display Size||7.9″|
|Display Resolution||2048 x 1536|
|Display Brightness||2000 cd/m²|
|Battery Chemistry||Lithium-Ion Polymer (LiPo)|
|Battery Capacity||7100 mAh / 82 Wh|
|Battery Configuration||3 S / 11.55 V|
|Maximum Charging Power||93 W|
|Charging Temperature||41 to 113°F / 5 to 45°C|
|Weight||12.9 oz / 365 g|
|AC Input Power||100 to 240 VAC, 50 / 60 Hz at 1.5 A|
|Output Voltage||13.2 V, 5 A
12 V, 1.5 A
9 V, 2 A
5 V, 3 A
|Power Rating||66 W|
|Operating Temperature||14 to 104°F / -10 to 40°C|
|Diagonal Size||15.6″ / 397 mm|
|Overall Dimensions||5.1 x 4.3 x 9.1″ / 130.0 x 108.0 x 230.0 mm (Folded)
22.0 x 4.3 x 18.0″ / 558.0 x 108.0 x 457.0 mm (Unfolded)
|Package Weight||25.7 lb|
|Box Dimensions (LxWxH)||22 x 19.4 x 10.4″|
