DJI Agras T30 Drone – Agriculture Spraying Drone Camera

DJI Agras T30 Drone

A New Flagship for Digital Agriculture

Introducing the DJI Agras T30 Drone

DJI Agras T30 Drone – UNBOXING

Branch-Targeting Technology for Thorough Penetration

With revolutionary branch-targeting technology and adjustable arms, the Agras T30 penetrates thick canopies with oblique spraying, ensuring an even application of liquid pesticides and doubling the number of droplets.  With the help of the Smart Agriculture Cloud Platform and cloud-based mapping, users can manage a 3D digital orchard, making it easy to get started with digital agriculture.

Ultrabright Screen Ultimate Control

Two Batteries + Charger for Continuous Operation

1,000 cycles for 4,942 acres

With fewer supporting components needed, the Agras T30 is easier to transport. A newly designed intelligent battery is covered by a warranty for 1,000 charges and 4,942 acres of flight; this ultra-long service life significantly reduces operating costs. The charging station and smart charging hub can fully charge a battery in 10 minutes, allowing for continuous operation with just two batteries and one charger. The standard safety box helps ensure battery safety and easy equipment storage.

T30 Spreading System 3.0

Large-capacity, Washable, and Corrosion-Resistant

Specifications

Hourly work efficiency

• 40 acres

High-precision radar

• √ Spherical Omnidirectional Radar System

Remote control planning accuracy

• √ (RTK/GNSS)

Pipe air exhaust

• √ One button Air Discharge

3D operation planning by the AI smart engine

• √

High-precision flowmeter

• √ (Dual-channel electromagnetic flowmeter with an error of ±2%)

Level gauge

• Continuous level gauge (with real-time pesticide load detection and intelligent supply-point prediction)

Maximum spray flow

• 7.2L/min (with the XR11001 nozzle)
  8L/min (with the XR110015 optional nozzle)

Pesticide tank installation method

• Fixed pesticide tank

Battery installation method

• Removable batteries

Single remote control for multiple drones

• √ (Single remote control for up to three drones)

D-RTK technology

• √

Top-view radar module

• √

Flight laser function

• √

Intelligent endurance/return function

• √

Intelligent supply-point prediction

• √

Front-view FPV

• √

Rear-view FPV

• √

Coordinated turning function

• √

Branch targeting technology

• √

Total weight (without batteries)

• 26.4 kg

Maximum take-off weight

• 78 kg (near sea level)

Maximum thrust-to-weight ratio

• 1.70 @ takeoff weight of 66.5 kg

Hovering precision (with good GNSS signal)

• With D-RTK enabled:
  ±10 cm (horizontal) and ±10 cm (vertical)
  With D-RTK disabled:
  ±0.6m (horizontal) and ±0.3m (vertical) (with the radar function enabled: ±0.1m)

RTK and GNSS frequency bands

• RTK: GPS L1/L2, GLONASS F1/F2, BeiDou B1/B2, and Galileo E1/E5
  GNSS: GPS L1, GLONASS F1, and Galileo E1

Maximum power consumption

• 11,000 W

Hovering power consumption

• 10,000 W (@ takeoff weight of 66.5 kg)

Hovering endurance

• 20.5min (@29,000 mAh & takeoff weight of 36.5 kg)
  7.8min (@29,000 mAh & takeoff weight of 66.5 kg)

Maximum pitch angle

• 15°

Maximum operating flight speed

• 7 m/s

Maximum level speed

• 10 m/s (with a good GNSS signal)

Maximum tolerable wind speed

• 8 m/s

Maximum flight altitude

• 4,500m
  *Reduce the pesticide load by 12% for each increase of 1,000 meters in altitude.

Recommended operating ambient humidity

• < 93%

Recommended operating ambient temperature

• 0℃ to 45℃

Maximum rotor distance

• 2,145 mm

Dimensions

• 2,858 mm × 2,685 mm × 790 mm (with arms and blades unfolded)
  2,030 mm × 1,866 mm × 790 mm (with arms unfolded and blades folded)
  1,170 mm × 670 mm × 857 mm (with arms folded)

Stator size

• 100×18 mm

KV value

• 77 rpm/V

Maximum pull

• 18.7 kg/rotor

Maximum power

• 3,600 W/rotor

Weight

• 756 g

Diameter × pitch

• 38×20 inch

Weight (with a single blade)

• 106 g

Maximum operating current (continuous)

• 60 A

Maximum operating voltage

• 60.9 V (14S LiPo)

View angle (FOV)

• Horizontal: 129°, vertical:82°

Resolution

• 1,280×720 15-30 fps

Nozzle model

• SX11001VS (standard)
  SX110015VS (optional)
  Fruit tree drones: TX-VK04 (optional)

Nozzle quantity

• 16

Maximum spray flow

• SX11001VS: 7.2L/min
  SX110015VS: 8L/min
  TX-VK4:3.6 L/min

Atomized particle size

• SX11001VS : 130 – 250 μm
  SX110015VS : 170 – 265 μm
  TX-VK4: 110 – 135 μm
  (depending on the actual operating environment, spray flow, and other factors)

Maximum effective spray width

• 4-9 m (with 12 nozzles and a distance of 1.5 to 3 meters to crops)

• Model

• WCH2

• Input voltage

• 17.3 – 26.2 V

• Output voltage and current

• 8.7V and 6A

• Operating ambient temperature

• 5℃ to 40℃

• Model

• A14-057N1A

• Input voltage

• 100 – 240V and 50/60 Hz

• Output voltage

• 17.4 V

• Rated power

• 57 W

Spreading system weight

• 3.9kg

Maximum opening area

• 44.6 cm²

Applicable materials

• Solid dry particles with a diameter of 0.5 to 5 mm

Spreading tank volume

• 40L

Maximum load of the spreading tank

• 35kg

Water-resistance rating

• IP67

Input voltage

• Power: 60V
  Control:15V

Maximum power

• 60V@250W
  15V@50W

Recommended operating ambient temperature

• 0℃ to 40℃

Dimensions

• 560×435×320mm

Maximum rotation speed

• 1,300 RPM

Dimensions

• 300×280×230 mm

Total weight

• 11.5 kg

Input voltage

• 100-264 Vac

Output voltage

• 40-60 V

Rated power

• 7,200

Charging current

• 120 A

Charging time

• Fully charges a battery in 9 to 12 minutes

Charging voltage accuracy

• +/-0.1 V

Charging current accuracy

• +/-1 A

Output channel quantity

• 2

Protection functions

• Over-temperature, over-voltage, under-voltage, short-circuit, and fan stall protection

Charging ambient temperature

Charging safety

• AC wire protection, power wire protection, and charge connector protection

Water pump model

• Plunger pump

Operating voltage

• 60 V

Maximum flow

Flow measurement range

• 0.25 – 20 L/min

Flow measurement error

• < ±2%

Measurable liquid

• Conductivity > 50 μS/cm, typical liquids: Tap water or aqueous organic or inorganic pesticides

Model

• RD2424R

Operating frequency

• SRRC/NCC/FCC: 24.05 – 24.25 GHz
  MIC/KCC/CE: 24.05 – 24.25 GHz

Operating power consumption

• 12 W

Equivalent isotropic radiated power (EIRP)

• SRRC: < 13 dBm; NCC/MIC/KCC/CE/FCC:< 20 dBm

Height maintenance and terrain adaptation

• Height measurement range: 1-30 m
  Height-maintenance range: 1.5-15 m
  Maximum slope in mountain mode:35°

Obstacle avoidance system

• Perceivable distance: 1.5-30 m
  View angle (FOV): Horizontal: 360°, vertical: ±15°
  Conditions of use: The relative altitude of the drone must be greater than 1.5 m and the speed less than 7 m/s
  Safety distance: 2.5 m (the distance between the tip of the propeller and the obstacle after the drone decelerates to a hover)
  Obstacle avoidance direction: Horizontally omnidirectional obstacle avoidance

Water-resistance rating

• IP67

Model

• RD2414U

Operating frequency

• SRRC/NCC/FCC:24.05 – 24.25 GHz
  MIC/KCC/CE:24.05 – 24.25 GHz

Overhead obstacle avoidance

• Perceivable distance: 1.5-10 m
  View angle (FOV): 80°
  Conditions of use: During take-off, landing, and climbing when the relative distance between the drone and the object above is greater than 1.5 m
  Safety distance: 2 m (the distance between the highest point on the top of the drone and the obstacle after the drone brakes and hovers stably)
  Obstacle avoidance direction: Above the drone

Water-resistance rating

• IP67

Equivalent isotropic radiated power (EIRP)

• SRRC:< 13 dBm; NCC/MIC/KCC/CE/
  FCC:< 20 dBm

Operating power consumption

• 4 W

Model

• BAX501-29,000mAh-51.8V

Weight

• Approximately 10.1 kg

Discharge rate

• 11.5C

Water-resistance rating

• IP54 with board-level potting protection

Capacity

• 29,000 mAh

Voltage

• 51.8 V

Model

• RM500-ENT

Operating frequency of the Ocusync Industry Edition

• 2.4000 – 2.4835 GHz
  5.725 – 5.850 GHz

Effective signal range at the Ocusync Industry Edition operating frequency (without interference and blockage)

• SRRC: 5 km; MIC/KCC/CE: 4 km; FCC: 7 km
  (measured when the operating height of the drone is 2.5 m)

EIRP of the operating frequency of the Ocusync Industry Edition

• 2.4 GHz
  SRRC/CE/MIC/KCC: 18.5 dBm;
  FCC: 29.5 dBm;
  5.8 GHz
  SRRC: 20.5 dBm;
  FCC: 28.5 dBm
  CE:12.5 dBm

Wi-Fi protocols

• Wi-Fi Direct, Wireless Display, and 802.11a/g/n/ac
  Supports 2 × 2 MIMO Wi-Fi

Wi-Fi operating frequency

• 2.4000 – 2.4835 GHz
  5.150 – 5.250 GHz
  5.725 – 5.850 GHz

Wi-Fi EIRP

• 2.4 GHz
  SRRC/CE: 18.5 dBm; FCC/MIC/KCC:20.5 dBm;
  5.2 GHz
  SRRC/FCC/CE/MIC: 14 dBm; KCC: 10 dBm;
  5.8 GHz
  SRRC/FCC: 18 dBm; CE/KCC: 12 dBm;

Bluetooth protocol

• Bluetooth 4.2

Bluetooth operating frequency

• 2.4000 – 2.4835 GHz

Bluetooth EIRP

• SRRC/MIC/FCC/CE/KCC:6.5 dBm

• Positioning

• GPS+GLONASS dual mode

Display screen

• 5.5-inch screen with a resolution of 1920×1080, brightness of 1,000 cd/m², and Android OS

Operating memory (RAM)

• 4GB LPDDR4

Storage space (ROM)

• A microSD card with 32 GB and extensible storage space for up to 128 GB, transfer speed rated as UHS-I Speed Grade 3

HDMI

• HDMI 1.4

Supported drones

• T30 and T10 agricultural drones

Operating power consumption

• 18 W

Operating ambient temperature

• -10℃ to 40℃

Storage ambient temperature

• -30℃ to 60℃ (within 1 month)
  -30℃ to 45℃ (more than 1 month and less than 3 months)
  -30℃ to 35℃ (more than 3 months and less than 6 months)
  -30℃ to 25℃ (more than 6 months)
  (with built-in batteries charged to 40% to 60%)

Charging ambient temperature

• 5℃ to 40℃

• Built-in batteries

• 18650 lithium-ion battery (5,000 mAh at 7.2V)

• Battery life

• 2 hours

• Charging method

• Use a standard 12V/2A USB fast charger

• Charging time

• 2.5 hours (use the 12V/2A USB fast charger when the remote control is powered off)

• Power supply current/voltage of the remote control USB-A port

• 5 V / 1.5 A

• Model

• WB37-4,920mAh-7.6V

• Battery type

• 2S LiPo

• Capacity

• 4,920 mAh

• Voltage

• 7.6 V

• Capacity

• 37.39 Wh

• Charging ambient temperature

• 5℃ to 40℃

• Battery life

• 2 hours
