MATRICE 300 RTK Drone Camera

840,000.00

DJI has launched the M300 RTK – a next-level commercial drone platform which offers enhanced flight performance and unrivalled safety features.

With a 55 minute maximum flight time, advanced AI capabilities, six directional sensing and positioning and the ability to carry three payloads – including hybrid camera solutions designed especially for the platform – this IP45-rated drone sets a new standard, combining intelligence with reliability.

The M300 RTK comes with free DJI Enterprise Shield (DJI Care Enterprise) – Basic to give operators peace of mind when conducting commercial missions. The protection package includes two replacements for a minimal replacement fee.

  • 55 min Max Flight Time, 23 m/s Max Flight Speed
  • 15 km Transmission Range, 1080p Triple-channel Video
  • Supports up to 3 payloads, 2.7 kg maximum payload capacity
  • Automate inspections with Live Mission Recording and AI Spot Check
  • Advanced algorithms enable PinPoint and Smart Track to obtain dynamic location information for subjects in view
  • 6 Directional Sensing and Positioning system enhances flight safety
  • Password-protected access to aircraft and data
  • AirSense ADS-B Receiver warns of nearby airplanes and helicopters
  • Secure data transmission with AES-256 encryption
  • DJI Pilot with Local Data Mode protects drone data
  • Operating Temperature: -20°C to 50°C
Spread the word

DJI MATRICE 300 RTK

The Matrice 300 RTK is DJI’s Latest commercial drone platform that takes inspiration from modern aviation system. Offering up to 55 minutes of flight time, advanced AI capabilities, 6 Directional Sensing and Positioning and more, the M300 RTK sets a whole new standard by combining intelligence with high-performance and unrivaled reliability.

MATRICE 300 RTK

MATRICE 300 RTK

MATRICE 300 RTK Test & Review

DJI MATRICE 300 RTK Superior Performance



Improved Transmission System

The all-new OcuSync Enterprise enables transmission up to 15 km away and supports triple-channel3 1080p video. Real-time auto-switching between 2.4 GHz and 5.8 GHz4 enables more reliable flight near high-interference environments, while AES-256 encryption offers secure data transmission.

Enhanced Flight Performance

The refined airframe and propulsion system design gives you a more efficient and stable flight, even in harsh conditions.

55min – Max Flight Time
7m/s – Max Descend Speed5
7000m – Service Ceiling6
15m/s – Wind Resistance
23m/s – Max Speed

Multiple Payload Configurations

Configure your M300 RTK to fit your mission needs. Mount up to 3 payloads simultaneously, with a maximum payload capacity of 2.7 kg.

Single Downward Gimbal

Single Upward Gimbal x Single Downward Gimbal

Single Upward Gimbal x Dual Downward Gimbals

Advanced Intelligence

Live Mission Recording

Record mission actions such as aircraft movement, gimbal orientation, photo shooting, and zoom level to create sample mission files for future automated inspections.

Waypoints 2.0

Create up to 65,535 waypoints and set multiple actions for one or more payloads, including 3rd party ones, at each waypoint. Flightpath planning is also optimized to maximize flexibility and efficiency for your missions.

AI Spot-Check7

Automate routine inspections and capture consistent results every time. Onboard AI recognizes the subject of interest and identifies it in subsequent automated missions to ensure consistent framing.

Smart Pin & Track8

PinPoint

Mark an object in camera or map view with a quick tap, and advanced sensor fusion algorithms will immediately calculate its coordinates, which are projected to all camera views as an AR icon. The location of the subject is automatically shared with another remote controller, or to online platforms such as DJI FlightHub9.



Smart Track

Identify and follow moving subjects like people, vehicles, and boats with the Smart Track function, where auto-zoom is applied for steady tracking and viewing. The subject’s dynamic location is continuously acquired and shared to another remote controller or to DJI FlightHub9

Aviation-Grade Situational Awareness

The M300 RTK adopts a new Primary Flight Display (PFD) that integrates flight, navigation, and obstacle information to empower the pilot with exceptional situational awareness.

Flight Information –  Flight information such as aircraft attitude, altitude, and velocity, as well as wind speed and wind direction, are all intuitively presented.

Navigation Display – Pilots can also view the live status of the aircraft’s heading, trajectory, PinPoint information, and home point projection, in a more efficient way. Visualize all nearby obstacles at once with the new obstacle map, so you can be fully informed.

A Powerful Vision System You Can Rely On – To enhance in-flight safety and aircraft stability, dual-vision and ToF sensors appear on all six sides of the aircraft, offering a maximum detection range of up to 40 m, with options to customize the aircraft’s sensing behavior via the DJI Pilot App. Even in complex operating environments, this 6 Directional Sensing and Positioning system helps keep the aircraft and the mission safe.

Professional Maintenance for Your Drone Fleet – The new integrated Health Management System displays the current status of all systems, notification logs, and a preliminary troubleshooting guide. Also in the system are the aircraft’s flight logs, duration, and mileage throughout its entire lifecycle, and tips on aircraft care and maintenance.

Purpose-built Applications

DJI Pilot – DJI Pilot is developed specifically for enterprise users to unleash the power of their DJI drones. With development made specifically for the M300 RTK, DJI Pilot optimizes your flight capability for peak performance.

DJI FlightHub – DJI FlightHub is a one-stop solution for managing your drone operations, supporting large organizations to effectively scale their aerial operations. Compatible with the M300 RTK, you can integrate FlightHub directly into your existing fleet of DJI drones and leverage its aerial intel across your organization.

Accessories



DJI Matrice 300 RTK Specifications



Aircraft

  • Dimensions
  • Unfolded, propellers excluded, 810×670×430 mm (L×W×H)
    Folded, propellers included, 430×420×430 mm (L×W×H)
  • Diagonal Wheelbase
  • 895 mm
  • Weight (with single downward gimbal)
  • Approx. 3.6 kg (without batteries)
    Approx. 6.3 kg (with two TB60 batteries)
  • Max Payload
  • 2.7 kg
  • Max Takeoff Weight
  • 9 kg
  • Operating Frequency
  • 2.4000-2.4835 GHz
    5.725-5.850 GHz
  • EIRP
  • 2.4000-2.4835 GHz:
    29.5 dBm (FCC); 18.5dBm (CE)
    18.5 dBm (SRRC); 18.5dBm (MIC)

    5.725-5.850 GHz:
    28.5 dBm (FCC); 12.5dBm (CE)
    28.5 dBm (SRRC)

  • Hovering Accuracy (P-mode with GPS)
  • Vertical:
    ±0.1 m (Vision System enabled)
    ±0.5 m (GPS enabled)
    ±0.1 m (RTK enabled)

    Horizontal:
    ±0.3 m (Vision System enabled)
    ±1.5 m (GPS enabled)
    ±0.1 m (RTK enabled)

  • RTK Positioning Accuracy
  • When RTK enabled and fixed:
    1 cm+1 ppm (Horizontal)
    1.5 cm + 1 ppm (Vertical)
  • Max Angular Velocity
  • Pitch: 300°/s, Yaw: 100°/s
  • Max Pitch Angle
  • 30° (P-mode, Forward Vision System enabled: 25°)
  • Max Ascent Speed
  • S mode: 6 m/s
    P mode:5 m/s
  • Max Descent Speed (vertical)
  • S mode: 5 m/s
    P mode:4 m/s
  • Max Descent Speed (tilt)
  • S Mode: 7 m/s
  • Max Speed
  • S mode: 23 m/s
    P mode:17 m/s
  • Service Ceiling Above Sea Level
  • 5000 m (with 2110 propellers, takeoff weight ≤ 7 kg) / 7000 m (with 2195 propellers, takeoff weight ≤ 7 kg)
  • Max Wind Resistance
  • 15 m/s
  • Max Flight Time
  • 55 min
  • Supported DJI Gimbals
  • Zenmuse XT2/XT S/Z30/H20/H20T
  • Supported Gimbal Configurations
  • Single Downward Gimbal, Dual Downward Gimbals, Single Upward Gimbal, Upward and Downward Gimbals, Triple Gimbals
  • Ingress Protection Rating
  • IP45
  • GNSS
  • GPS+GLONASS+BeiDou+Galileo
  • Operating Temperature
  • -20°C to 50°C (-4°F to 122° F)

Remote Controller

  • Operating Frequency
  • 2.4000-2.4835 GHz
    5.725-5.850 GHz
  • Max Transmitting Distance (unobstructed, free of interference)
  • NCC/FCC: 15 km
    CE/MIC: 8 km
    SRRC: 8 km
  • EIRP
  • 2.4000-2.4835 GHz:
    29.5 dBm (FCC) 18.5dBm (CE)
    18.5 dBm (SRRC); 18.5dBm (MIC)

    5.725-5.850 GHz:
    28.5 dBm (FCC); 12.5dBm (CE)
    20.5 dBm (SRRC)

  • External battery
  • Name: WB37 Intelligent Battery
    Capacity: 4920 mAh
    Voltage: 7.6V
    Type: LiPo
    Energy: 37.39Wh
    Charging time (using BS60 Intelligent Battery Station): 70 minutes (15°C to 45°C); 130 minutes (0°C to 15°C)
  • Built-in battery
  • Type: 18650 lithium ion battery (5000 mAh @ 7.2 V)
    Charging: Use a USB charger with specification of 12V / 2A
    Rated power: 17 W
    Charging time: 2 hours and 15 minutes (Using a USB charger with specification of 12V / 2A)
  • Battery Life
  • Built-in battery: Approx. 2.5h
    Built-in battery+External battery: Approx. 4.5h
  • USB Power Supply
  • 5 V / 1.5 A
  • Operating Temperature
  • -20°C to 40°C (-4 °F to 104 °F)

Vision System

  • Obstacle Sensing Range
  • Forward/Backward/Left/Right: 0.7-40m
    Upward/Downward: 0.6-30m
  • FOV
  • Forward/Backward/Downward: 65° (H), 50° (V)
    Left/Right/Upward: 75°(H), 60°(V)
  • Operating Environment
  • Surfaces with clear patterns and adequate lighting (> 15 lux)



Infrared ToF Sensing System

  • Obstacle Sensing Range
  • 0.1-8m
  • FOV
  • 30° (±15°)
  • Operating Environment
  • Large, diffuse and reflective obstacles (reflectivity >10%)



Top and bottom auxiliary light

  • Effective lighting distance
  • 5 m



FPV Camera

  • Resolution
  • 960p
  • FOV
  • 145°
  • Frame rate
  • 30 fps



Intelligent Flight Battery

  • Name
  • TB60
  • Capacity
  • 5935 mAh
  • Voltage
  • 52.8 V
  • Battery Type
  • LiPo 12S
  • Energy
  • 274 Wh
  • Net Weight
  • Approx. 1.35 kg
  • Operating Temperature
  • -4°F to 122°F (-20°C to 50°C)
  • Ideal storage temperature
  • 71.6°F to 86°F (22°C to 30°C)
  • Charging Temperature
  • -4°F to 104°F (-20°C to 40°C)
    (When the temperature is lower than 5°C, the self-heating function will be automatically enabled. Charging in a low temperature may shorten the lifetime of the battery)
  • Charging time
  • Using BS60 Intelligent Battery Station:
    220V input: 60 minutes (fully charging two TB60 batteries), 30 minutes (charging two TB60 batteries from 20% to 90%)
    110V input: 70 minutes (fully charging two TB60 batteries), 40 minutes (charging two TB60 batteries from 20% to 90%)

BS60 Intelligent Battery Station

  • Dimensions
  • 501*403*252mm
  • Net Weight
  • 8.37kg
  • Maximum Capacity
  • TB60 Intelligent Flight Battery × 8
    WB37 Intelligent Battery × 4
  • Input
  • 100-120 VAC, 50-60 Hz / 220-240 VAC, 50-60 Hz
  • Max. Input Power
  • 1070W
  • Output Power
  • 100-120 V: 750 W
    220-240 V: 992 W
  • Operating Temperature
  • -4°F to 104°F (-20°C to 40°C)

WHAT’S IN THE BOX

DJI MATRICE 300 RTK

Item

Quantity

Aircraft Body x1
DJI Smart Controller Enterprise x1
TB60 Batteries for Matrice 300 RTK x2
BS60 Battery Charging Station x1
USB Charger x1
USB-C Cable x1
WB37 Intelligent Battery x1
2110 Propeller (CW) x2
2110 Propeller (CCW) x2
Landing Gear x2
Spare Stick Cover (pair) x1
Spare Propeller Holder x2
Spare Gimbal Damper x4
USB Cable (with Double A Ports) x1
Vision System Calibration Plate x1
Carrying Case x1
Smart Controller Lanyard x1
Rubber Port Cover (Set) x1
MScrews and Tools x1
Power Lead x1

Click here to download the user manual of DJI Air 2S Fly More Combo

Click here for expert reviews on DJI Air 2S Fly More Combo

DJI MATRICE 300 RTK Frequently Asked Questions (FAQs)

Can the downward single gimbal connector be replaced with a dual gimbal connector?

A: Yes.
To ensure safety, before replacing the gimbal connector, it is recommended to power off the aircraft and remove the TB60 Intelligent Flight Batteries.

What is the ingress protection rating of the M300 RTK? Can I fly in the rain?

A: The Matrice 300 RTK has a protection rating of IP45. However, the protection rating is not permanently effective and may decrease due to wear and tear. Do not fly in rain heavier than 100mm/24h.

Which propellers come with the M300 RTK?

A: The M300 RTK comes with standard 2110 propellers. You could also use the 2195 high altitude low noise propellers.

How many batteries can the Battery Station charge at the same time?

A: It can simultaneously store eight TB60 Intelligent Flight Batteries and four WB37 Intelligent Batteries. It can charge two TB60 Intelligent Flight Batteries and one WB37 Intelligent Battery at the same time. Batteries with the highest battery levels will be recharged first, followed by the ones with lower levels.
