Autel Robotics EVO MAX 4T Drone

  • No Geofencing
  • 8K 10x Optical Zoom
  • Thermal Camera:640×512 | 16x Digital Zoom
  • Wide Camera: 50MP | 1/1.28″ CMOS
  • Zoom Camera: 48MP | 8K 10x Optical Zoom(160x Max)
  • Laser Rangefinder
  • Autel SkyLink 3.0 | 12.4 miles Transmission Range
  • 720° Obstacle Avoidance
  • 42 mins Max Flight Time
  • A-Mesh 1.0 | Mesh Networking Technology
  • 3D Map Planning | Multiple Mission Types | Data Security
  • Multi-channel Projection Screen*
  • Autel SDK

₹835,000.00

  • 1 Year warranty
  • 14-Days Return & Refund
  • Free Delivery

Autel EVO Max 4T – A Leader of Drone Intelligence

The EVO Max 4T brings powerful technologies and advanced autonomy to users. EVO Max 4T assesses complex environments to create real-time 3D flight paths for unparalleled obstacle avoidance. Advanced sensors make flight in GPS unavailable areas possible and the incredible new thermal payload unlocks new object identification and tracking scenarios. With a foldable, weather-resistant design, the EVO Max 4T is as portable as it is capable.

No Blind Spots

Ultimate Obstacle Avoidance

EVO Max 4T is the only commercial drone that combines traditional binocular vision systems with millimeter wave radar technology. This allows the EVO Max 4T’s onboard Autel Autonomy Engine to perceive objects down to 0.5 inch, eliminating blind spots and enabling operation in low light or rainy conditions.

Anti Jam, Anti Interference

The EVO Max 4T uses advanced flight control modules and algorithms specially designed to counter RFI, EMI, and GPS spoofing. This enables the EVO Max 4T to fly confidently near power lines, critical structures, and in complex areas.

Weather Rating-IP43

The EVO Max 4T has an IP43 Ingress Protection rating, which means it is protected from solid objects larger than 1mm and from water jets that are aimed up to 60 degrees from vertical.

Autel SkyLink 3.0

The EVO Max 4T SkyLink 3.0 system comes with 6 antennas, 4 frequency bands, AES-256 encryption*, and optional 4G integration* to provide users with the most advanced flight capabilities ever in an EVO.

Specifications

Weight 3.5 lbs (1600g, battery and gimbal included)
Dimensions 576*660*149 (folded, incl. propellers) 340*407*148(folded, excl. propellers) 257*136*133 (unfolded, excl. propellers)
Diagonal Wheelbase 1.52 ft (464mm)
Max Ascent Speed 8m/s
Max Descent Speed 6m/s
Max Horizontal Speed (windless near sea level) 22m/s
Max Service Ceiling Above Sea Level 23000ft (7000m)
Max Flight Time (windless) 42 mins
Max Hovering Time (windless) 40 mins
Max Wind Resistance 27mph* *Takeoff and landing can withstand wind speeds up to 27 mph (12 m/s).
IP Rating IP43
Max Tilt Angle 35°
Max Angular Velocity Pitch: 300°/s; Yaw: 120°/s
Operating Temperature -4°F to 122°F (-20℃ – 50℃)
Operating Frequency 2.4G/5.2G*/5.8G/900MHz*
Transmitter Power (EIRP) 2.4GHz:<33dBm(FCC), 20dBm(CE/SRRC/MIC) 5.8GHz:33dBm(FCC), <30dBm(SRRC), <14dBm(CE) 5.15-5.25GHz: < 23dBm(FCC/SRRC/MIC) 5.25-5.35GHz:<30dBm(FCC), <23dBm(SRRC/MIC)
Hovering Accuracy Vertical: ±0.1 m (Vision System enabled); ±0.3 m (GPS enabled); ±0.15 m (RTK enabled); Horizontal: ±0.15 m (Vision System enabled); ±0.3 m (GPS enabled);
Mechanical Range Pan: -135° to 45° Tilt: -45° to 45° Roll: -100° to 100°
Controllable Range -90° to 45°
Stable system 3-axis mechanical gimbal (pitch, tilt, roll)
Max Control Speed (pitch) 200º/s
Angular Vibration Range <0.005°
Sensor 1/2″ CMOS, Effective pixels: 48M
Lens Focal length: 11.8-43.3mm (35mm, equivalent: 64-234mm) Aperture: f/2.8-f/4.8
Exposure Compensation ±3EV 0.3EV/step
ISO Range Normal Mode： Auto: ISO100 ~ ISO6400 Manual: Photo: ISO100 ~ ISO12800 Video: ISO100 ~ ISO6400
Shutter Speed Photo: 8s ~ 1/8000s Video: 1s ~ 1/8000s
Max Photo Size 8000×6000
Max Video Resolution 7680×4320
Sensor 1/1.28 CMOS, Effective pixels: 50M
Lens DFOV: 85° Focal length: 4.5 mm (equivalent: 23 mm) Aperture: f/1.9 AF motor: 8-wire SMA, PDAF focus
Exposure Compensation ±3EV 0.3EV/step
ISO Range Auto: Photo: ISO100~ISO6400 Video: ISO100~ISO64000 (Night scene mode: up to ISO64000) Manual: Photo: ISO100~ISO12800 Video: ISO100~ISO6400
Shutter Speed Photo: 8s ~ 1/8000s Video: 1s ~ 1/8000s
Max. Video Resolution 3840×2160
Photo Size 8192*6144 4096*3072
Thermal Imager Uncooled VOx Microbolometer
Lens DFOV: 64°
Aperture: 13mm
Focus: f/1.2
Infrared Temperature Measurement
Accuracy		 26.6~37.4 ℉ or reading ±3% (using
the larger value) @ambient
temperature -4℉ to 140℉
Video Resolution 640*512
Photo Size 640*512
Pixel Pitch 12 um
Temperature Measurement Method Center measurement, pot measurement, rectangular measurement
Temperature Measurement Range -4℉ to 302℉, 32℉ to 1022℉ (-20°C to
150°C, 0 to 550°C)
Temperature Alert High and low temperature alarm thresholds, reporting coordinates and temperaturevalues
Measurement Accuracy ±1m
Measuring Range 1.2km
Operating Frequency 2.4G/5.2G*/5.8G/900MHz*
Max Transmission Distance (unobstructed, free of interference) 20km
Independent Networking 7.9-inch Smart Controller
Transmitter Power (EIRP) 2.4GHz:<33dBm（FCC）, <20dBm(CE/SRRC/MIC) 5.8GHz:<33dBm(FCC), <30dBm(SRRC), <14dBm(CE) 5.15-5.25GHz: <23dBm(FCC/SRRC/MIC)
Non-GPS Hovering and Manual Flight Indoor: Horizontal error ≤3cm （At least have texture at one direction） Outdoor: Daytime: Within 500m flight height, horizontal error < 0.01*height Night: Manual flight is controllable within 100m flight height
Non-GPS Return-to-Home Within 500m flight height, horizontal error of Return-to-Home point < 30cm
Automatic Obstacle Rerouting High Speed Obstacle Rerouting: Flight speed up to 20m/s when Min. safety distance to obstacle is 1.5m High Precision Obstacle Rerouting: Flight speed could reach 3m/s when Min. safety distance to obstacle is 0.2m
Multi-target Recognition and Tracking Target identification types: people, vehicles, boats Number of targets detected: 64 Comprehensive recognition accuracy: > 85%
Frequency 60Ghz~64Ghz
Size 38*14*2mm
Weight 2g
EIRP 18dbm
Distance Detection Range For Obstacle Avoidance：0.2m~100m For Height Measurement：0.05m~200m
Ranging Accuracy For Obstacle Avoidance：0.1m For Height Measurement：0.02m
Speed Measurement Range ± 60m/s（4D Mode）；±28m/s（3D Mode）；
Speed Measurement Accuracy ≤1%
Max. Tracking Target Number 32
Obstacle Sensing Range Forward/Upward/Downward/Backward/Sideward: 0.2~50m
FOV Forward/Backward/Sideward: 60°(H)，80°(V) Upward/Downward: 360°(H)，190°(V)
Screen 7.9 inch, 2000nits max. brightness, 2048*1536 resolution
External Battery Capacity: 5800mAh Voltage: 11.55V Battery Type: Li-on Energy: 67Wh Charing time: 120mins Intelligent Lithium Ion Battery
Operating Time 3 hours (Max. brightness) 4.5 hours (50% brightness)
Max Transmission Distance (with interference) FCC: 20km CE: 7km
Storage 128G
GNSS GPS+GLONASS+Galileo+Beidou
Operating Temperature -20℃ to 40℃
Protocol WiFi Direct, Wi-Fi Display, 802.11a/b/g/n/ac Support 2 x 2 MIMO Wi-Fi
Operating Frequency 2.400 – 2.4835 GHz； 5.150 – 5.250GHz； 5.725 ‒ 5.850 GHz
Transmitter Power (EIRP) 2.400 – 2.4835 GHz FCC/CE:≤20dBm 5.150 – 5.250GHz FCC:≤17dBm 5.725 ‒ 5.850 GHz FCC:≤17dBm CE:≤14dBm
Capacity 8070mAh
Voltage 14.88V
Battery Type LiPo 4S
Energy 120wh
Net Weight 520g
Charging Temperature 5ºC to 45ºC(When the temperature is lower than 10° C (50° F), the selfheating function will be automatically enabled. Charging in a low temperature may shorten the lifetime of the battery)
Hot Swap Support
