Flyability Elios 2 Intuitive Indoor Inspection Drone

3,800,000

  • Designed For Confined Spaces
  • Intuitive To Fly
  • Accurate Data Capture
  • Build Upon Actionable Data
  • Up to 10 min Flight Time
  • 5200 mAh Battery Capacity
  • Auto-landing on signal lost

1-Year Warranty     7 days return policy     PAN India Fast Shipping

Available on backorder

Description

Flyability Elios 2

The most user-friendly, trustworthy, and accurate indoor inspection drone is Elios 2. Use cutting edge drone data capturing capabilities to accomplish perfect inspections while keeping your workers safe from damage from the very first flight.

Intuitive To Fly

GPS Free Stabilization Stay in Control at All Times. Distance-Lock Capture Of Long Pattern. Full HD Live Streaming Feels Like You’re There.

ELIOS 2 INTUITIVE INDOOR INSPECTION

The Elios 2 Intuitive Indoor Inspection Drone is a cutting-edge piece of technology that is revolutionizing the way inspections are conducted in hard-to-reach indoor spaces. With its compact and sturdy design, the Elios 2 is able to navigate through narrow passages, confined spaces, and harsh environments that are too hazardous for humans to access. This drone is equipped with a high-resolution camera and powerful lighting that enables it to capture high-quality images and videos, even in low-light conditions.

ELIOS 2 INTUITIVE INDOOR INSPECTION

One of the most impressive features of the Elios 2 is its intuitive piloting system, which allows even novice operators to fly the drone with ease. The drone can be controlled using a simple remote or a tablet, making it easy to maneuver and adjust its position. The Elios 2 also has collision-tolerant technology, which means it can safely navigate around obstacles and avoid collisions without causing any damage.

ELIOS 2 INTUITIVE INDOOR INSPECTION

Built for your success

Our mission is to provide you with the tools and resources you need to achieve your goals and reach your full potential.

ELIOS 2 INTUITIVE INDOOR INSPECTION

Specifications

AIRCRAFT

CONFIGURATION Quadcopter
DIMENSIONS Fits in a < 400 mm sphere; 15.75 in
MOTORS 4 fast reversing electric brushless motors
MOTOR POWER RATING 120W average power, 750W nominal peak power
PROPELLERS 4 propellers, 5 inches
TAKE-OFF WEIGHT < 1450 g; < 3,2 lbs.
Includes battery, payload & protection
MAX FLIGHT TIME Up to 10 min
MAX ASCENT SPEED 1.3 m/s; 4.3 ft/s MAX DESCENT SPEED 1.3 m/s; 4,3 ft/s
MAX SPEED 1.3 m/s (Assist mode); 4,3 ft/s
4 m/s (Atti mode); 13 ft/s
6.5 m/s (Sport mode); 21 ft/s
MAX PITCH/ROLL ANGLES 0.15 rad (Attitude mode)
0.2 rad (Assist mode)
0.3 rad (Sport mode)
MAX WIND RESISTANCE 3 m/s (Assist mode); 10 ft/s
5 m/s (Sport mode); 16,4 ft/s
FLIGHT CONTROL SENSORS IMU, magnetometer, barometer, 7 vision and distance sensors
MATERIALS Carbon fiber composites, magnesium alloy, aeronautical grade aluminum,
high-quality thermoplastics
OPERATING TEMP.
0 ºC to 50 ºC1
* (32 °F to 122 °F)
FLIGHT MODES ASSIST – Assist mode
ATTI – Attitude mode
SPORT – Sport mode
FAIL-SAFE Auto-landing on signal lost
Forced-descent when battery critically low
OPERATING FREQUENCY 2404 – 2483 MHz (UAV to RC)
EIRP 2.4 GHz: ≤ 32 dBm (FCC); ≤20 dBm (CE); ≤10 dBm/MHz (MIC)
INGRESS PROTECTION Splash and dust resistant
NOISE LEVEL 99 dB(A) hover
120 dB(A) max @ 1m

SMART BATTERY

RATED CAPACITY 5200 mAh
NOMINAL VOLTAGE 19 V
BATTERY TYPE LiPo 5S HV Smart Battery:
– Improved safety (protection for: overcharge, overcurrent, over/undertemperature)
– Plug-and-play charging
– Self-balancing
– Storage self-discharge
– Cycle counter
– Battery ID
ENERGY 98.8 Wh
CHARGING TIME 1.5 h
BATTERY CHANGE TIME < 1 min

MAIN CAMERA

SENSOR 1/2.3″ CMOS
Effective Pixels: 12.3 M
Sensitivity: Optimized for low light performance
PHOTO FORMATS JPG VIDEO FORMATS MOV
VIDEO RECORDING RESOLUTIONS 4k Ultra HD: 3840 x 2160 at 30 fps
FHD: 1920 x 1080 at 30 fps VIDEO STREAMING RESOLUTION FHD: 1920 x 1080 at 30 fps or SD 640 x 480 at 30fps
MOVIE FOV 114° horizontal, 130.8° diagonal
PHOTO FOV 118.8° horizontal, 148.6° diagonal
TOTAL VERTICAL FOV approximately 260° including camera tilt
LENS 2.71 mm focal length
Fixed focal CONTROL MODES Auto mode with manual EV compensation
FILE STORAGE MicroSD card (onboard the aircraft)
Min Capacity: 64GB
Max capacity: 128 GB
Recommended model: Sandisk Extreme micro SDXC UHS-I V30
SUPPORTED FILE SYSTEM exFAT

THERMAL CAMERA

SENSOR Lepton 3.5 FLIR
VIDEO RECORDING RESOLUTION 160 x 120 at 9 fps
LENS FOV 56° x 42°, Depth of field 15cm to infinity
SENSITIVITY (NEDT) <50 mK
TEMPERATURE RANGE -10°C to 140°C (14°F to 284°F)
WAVELENGTH (LWIR) 8-14 μm
FILE STORAGE MicroSD card (onboard the aircraft)
Max capacity: 32 GB
Recommended model: Sandisk Extreme micro SDXC UHS-I V30
SUPPORTED FILE SYSTEM FAT32

REMOTE CONTROLLER

OPERATING FREQUENCIES 2404 – 2483 MHz (RC to UAV)
5738 – 5808 MHz (RC to RC)
920.6 – 928 MHz (RC to RC, Japan only) MAX TRANSMISSION DISTANCE Up to 500 m in direct line of sight
EIRP 2.4 Ghz ≤20 dBm, 5.8 GHz ≤13 dBm, 920 MHz ≤10 dBm WEIGHT 810 g (924 g with tablet holder) OPERATING TEMP. 0 °C to 40 °C
OUTPUT PORT HDMI, SDI, USB
BATTERY 6000 mAh 2S
CONTROLS Aircraft control and payload settings
OPTIONS Optional remote controller (camera operator) with video stream reception on a
secondary screen, and dual control of camera settings. BATTERY CHARGER 17.4 V / 57 W
