Sony FX30 Digital Cinema Camera with XLR Handle Unit

26.1 MP APS-C BSI CMOS sensor for high-resolution capture
Records UHD 4K up to 120 fps, with oversampling from 6K for cleaner 4K
10-bit 4:2:2 color sampling internally; 16-bit RAW output via HDMI
Dual Base ISO (800 / 2500) for better low-light performance
In-body 5-axis image stabilization + Active Mode for handheld video
Fast Hybrid Autofocus with Real-time Eye/Face/Tracking capabilities
Detachable XLR handle unit with 2 XLR inputs + 3.5 mm input; supports 4-channel audio when used
Dual CFexpress Type A / SD UHS-II memory card slots
Fully articulating 3.0″ touchscreen LCD (≈ 2.36 million dots)
Rugged, compact form for cage-free handheld use

Description

Product Overview

Category	Specification
Model / Series	Sony FX30 (ILME-FX30)
Sensor	APS-C (23.3 × 15.5 mm), Exmor R BSI CMOS
Effective Pixels (Still / Movie)	Still: ~26.0 MP; Movie: ~20.1 MP
Total Pixels	~27.0 MP
ISO Range (Still / Movie)	100 – 32,000 (expandable 50 – 102,400)
Dual Base ISO	800 / 2500 (when using S-Log3)
Shutter (Still / Movie)	1/8,000 to 30 s (electronic); movies also allow 1/8,000 down to ¼ sec; “Angle” mode support
Exposure Compensation	±5.0 EV (1/3 or 1/2 EV steps)
Metering	1,200-zone evaluative metering
Autofocus / Focus System	Phase-detection + contrast; sensitivity –3 EV to +20 EV (ISO 100, f/2)
AF Points	759 (video) / 627 (still)
Image Stabilization	5-axis sensor-shift + Active Mode
Recording Formats / Codecs	XAVC HS (HEVC), XAVC S (H.264), XAVC S-I, proxies, RAW via HDMI
Max Video Resolution & Frame Rates	3840×2160 up to 120p (with 1.62× crop in 120p)
LCD / Monitor	3.0″ articulating touchscreen, 2,359,296 dots
Card Slots / Media	Dual slots: CFexpress Type A / SD (UHS-I & UHS-II)
Connectivity / Interfaces	USB-C (USB 3.2 Gen1 / Power Delivery), Micro USB, HDMI Type A, 3.5 mm mic & headphone jacks
Wireless / Network	Wi-Fi 802.11 a/b/g/n/ac; Bluetooth 5.0
Power / Battery	NP-FZ100 battery; power via USB PD; consumption ~5.6 W (video)
Operating Temp / Storage Temp	0 °C to 40 °C ; –20 °C to 55 °C
Dimensions	129.7 × 77.8 × 84.5 mm (W × H × D)
Weight	~646 g (with battery and card, excluding XLR handle)
XLR Handle Unit (supplied)	Adds ~305 g; supports 2 XLR/TRS inputs + 3.5 mm stereo; 4-channel audio when used
Other Features / Highlights	S-Cinetone, LUT preview, timecode sync, tally lamps, breathing compensation, metadata recording

Sony FX30 Digital Cinema Camera Overview

The Sony FX30 combines the power of a newly-developed APS-C sensor with a cinema-grade imaging pipeline, delivering a versatile camera for content creators and aspiring filmmakers. Lightweight yet feature-rich, it offers intuitive operation and professional-level capabilities, making it a perfect companion for all levels of filmmaking.

Cinematic Performance

Advanced APS-C/Super 35mm Sensor

Capture stunning visuals with the 26MP APS-C Exmor R BSI CMOS sensor, paired with the BIONZ XR processor, offering cinematic-quality 10-bit UHD 4K video up to 120 fps. This high-performance system captures over 14 stops of dynamic range, while the Dual Base ISO (800 / 2500) ensures exceptional low-light performance.

High-sensitivity recording up to ISO 32,000.
Full-pixel readout from the 6K sensor delivers sharp UHD 4K up to 60 fps.
4K recording at 120 fps (1.6× crop) and Full HD up to 240 fps.
HDMI output supports 16-bit RAW video to compatible recorders.

Professional Picture Control

The FX30 gives filmmakers the freedom to create footage ready for publication or high-end post-production:

S-Cinetone delivers natural skin tones, smooth highlights, and cinematic color science borrowed from Sony’s VENICE line.
Flexible Picture Profiles including S-Log3 and HLG maximize dynamic range for post-processing.
Apply Creative Looks during recording to set the mood on the fly, reducing post-production effort.
Store up to 16 user LUTs and 3 presets for accurate monitoring via the LCD, EVF, or HDMI output.

Sony FX30 Digital Cinema Camera with XLR Handle Unit

Designed for Every Filmmaker

Flexible Shooting Modes

Sony’s FX30 supports three log modes to suit any level of expertise:

Flexible ISO – ideal for beginners, offering easy ISO control.
Cine EI – captures maximum dynamic range with manually selected base ISO.
Cine EI Quick – automatically switches between base ISOs for seamless operation.

Fast Hybrid Autofocus

The FX30 delivers high-speed, precise AF even at 4K 120 fps:

495 AF points in video, 759 in photo mode, covering 90% of the sensor.
Real-time Eye AF tracks humans and animals.
AF Assist switches automatically to manual focus when needed.
Focus Map visualizes depth of field for accurate control.

5-Axis In-Body Image Stabilization

Capture smooth handheld footage with 5-axis IBIS. Active Mode combines optical and digital stabilization for ultra-stable results. Even gyro data can be recorded for post-production stabilization.

Comprehensive Feature Set

The FX30 integrates advanced cinema features for professional results:

Breathing compensation for smooth focus transitions.
Timecode sync via optional VMC-BNCM1 cable.
Tally lights to indicate recording status.
Full metadata recording for post-production with Catalyst Browse and Prepare.
Includes gyro, lens stabilization, and shot marking data.

Ergonomic & Portable Design

The FX30’s compact body (just 1.2 lb) enables cage-free handheld shooting:

Fully customizable button layout.
Dedicated zoom rocker for smooth zooming.
Multiple 1/4″-20 threaded mounting points for accessories.
Multi Interface Shoe supports advanced accessories, including the XLR handle.
Active cooling fan allows extended shooting without interruption.
Compatible with FX3 accessories, including cages.

Connectivity & Media Options

Stay flexible on set with professional connectivity:

Full-size HDMI for clean 4K 60p or 16-bit RAW output.
3.5mm mic & headphone jacks, plus USB-C for fast data transfer and power.
Multi-Terminal (Micro-USB) for remotes and accessories.
Dual CFexpress Type A / SD slots support high-bitrate and high-frame-rate recording.

Professional Audio with XLR Handle Unit

The detachable XLR Handle Unit enhances audio recording:

Two XLR/TRS combo inputs + one 3.5mm stereo input.
Record up to 4 audio channels simultaneously.
Ergonomic design with physical gain dials and accessory mounting threads.
Securely attaches to the Multi Interface Shoe for stable operation.

Intuitive Menu & Controls

Sony updated the FX30 menu system for faster access to essential settings:

Quick view of Picture Profile, recording format, white balance, aperture, ISO, and more.
Optimized shooting screen layout keeps the image clear while monitoring settings.

Summary

The Sony FX30 combines cinema-grade imaging, professional audio, and intuitive controls in a lightweight, versatile body. Perfect for filmmakers, content creators, and solo operators, it empowers you to create cinematic-quality projects anywhere.
