Description
Product Overview
| Category | Specification |
|---|---|
| Model | Sony PXW-Z280 |
| Image Sensor | 3 × 1/2-inch Exmor R CMOS sensors |
| Effective Resolution | 3840 × 2160 pixels (4K) |
| Lens / Zoom | 17× Fujinon optical zoom; 30.3–515 mm (35 mm equivalent) |
| Maximum Aperture | f/1.9 (at wide) |
| Minimum Aperture | f/16 |
| Filter Thread | Ø77 mm |
| Control Rings | Independent focus, zoom, and iris rings (with end stops) |
| ND Filters | Built-in mechanical ND (Clear, 2-stop, 4-stop, 6-stop) + electronic variable ND (1/4 to 1/128) |
| Recording Formats | XAVC-Intra, XAVC-Long, MPEG HD, DVCAM |
| Frame Rates (4K) | 23.98 / 25 / 29.97 / 50 / 59.94 fps |
| Frame Rates (HD) | Up to 59.94 fps (various modes) |
| Simultaneous Recording | 4K + HD simultaneous recording supported |
| HDR / Gamma Modes | HLG (Hybrid Log Gamma), S-Log3 |
| Viewfinder / LCD | 0.5-inch OLED VF, high resolution 2.36 million dots |
| Mass / Weight | • Body only: ~2.6 kg • With lens hood, eyecup, battery, SxS card: ~3.0 kg |
| Dimensions (W × H × D) | 178.4 × 202.0 × 426.3 mm (with accessories) |
| Power Requirements | DC In: 12 V; Battery: 14.4 V |
| Power Consumption | ~24 W (LCD Off, EVF On) ~31 W (LCD On & external device used) |
| Battery Life | • BP-U30 battery: ~1 h 5 min (LCD Off, etc.) • BP-U60: ~2 h 10 min • BP-U90: ~3 h 15 min (under similar conditions) |
| Operating Temp. | 0 °C to 40 °C |
| Storage Temp. | –20 °C to +60 °C |
| Audio Inputs / Channels | 4-channel audio; 2 × XLR inputs; further two channels via MI shoe wireless receiver inputs |
| Media / Storage | Dual SxS card slots (for simultaneous, relay, or backup recording) |
| Video Outputs / Interfaces | 12G-SDI, HDMI, BNC (component), USB, timecode / genlock I/O, Ethernet, dual MI shoe |
| Networking / Streaming | Built-in dual-band Wi-Fi (2.4 / 5 GHz); supports RTMP / RTMPS streaming, FTP transfer, “XDCAM air” workflows |
| Autofocus / Face Detection | Face Detection AF with “Face Priority AF” and “Face Only AF” modes |
| HLG / Instant HDR Workflow | Support for HLG enables direct HDR output without extensive grading |
| Sensitivity / Low Light | High sensitivity (noted “F12 @ 59.94p” in some specs) |
| Accessories (Typical Bundle) | Lens hood, EVF eyecup, BP-U30 battery, BC-U1A charger, power cord, USB cable, shoulder strap |
Sony PXW-Z280 4K 3CMOS 1/2″ Sensor XDCAM Camcorder – Overview
The Sony PXW-Z280 is a professional-grade 4K XDCAM camcorder built to deliver stunning image quality, exceptional HDR performance, and flexible production workflows. Equipped with three 1/2″-type Exmor R CMOS sensors, the PXW-Z280 captures rich detail with incredible depth of field, low-light sensitivity, and true-to-life color accuracy. Whether you’re shooting documentaries, news, or live events, this camera ensures reliable performance and cinematic visuals every time.
The integrated 17x optical zoom Fujinon lens offers precise control with independent focus, zoom, and iris rings, allowing smooth manual operation. Its electronically variable ND filter enables seamless exposure adjustments — perfect for dynamic shooting conditions.
Dual HDR/SDR Production Made Simple
Designed for modern broadcasting needs, the PXW-Z280 supports both S-Log3 and HLG (Hybrid Log-Gamma) gamma profiles. Capture footage with maximum dynamic range for professional color grading, or use Instant HDR Workflow to shoot, edit, and deliver vivid HDR content instantly — without the need for time-consuming post-production.
You can record 4K and HD simultaneously or output 4K 60p directly through the built-in 12G-SDI port, ensuring a smooth and efficient workflow for any production environment.
Versatile 17x Zoom Lens
The 17x Fujinon optical zoom lens covers a versatile 30.3 to 515 mm (35 mm equivalent) range — perfect for wide shots and distant subjects alike. For HD recording, you can extend this reach with up to 34x digital zoom, while maintaining sharp image quality. The manual control rings make it easy to adjust focus, iris, and zoom independently, offering professional control in the field.
Optimized HDR Imaging
The PXW-Z280 brings flexibility to HDR production with two powerful workflows:
-
S-Log3 Gamma – captures the full dynamic range for ultimate color grading flexibility.
-
HLG (Hybrid Log-Gamma) – supports Instant HDR, enabling you to shoot, edit, and view HDR content directly without grading.
Whether you’re working in a controlled studio or on location, the PXW-Z280 ensures consistent, broadcast-quality HDR output.
Fast, Reliable Autofocus
Featuring Face Detection Autofocus (AF), the PXW-Z280 keeps your subject sharp and in focus, even during unpredictable movement. Choose between Face Priority AF or Face Only AF modes to suit your shooting style — ideal for interviews, run-and-gun shooting, or live coverage.
Built-In Streaming & Dual-Link Connectivity
Stay connected anywhere with integrated dual-band Wi-Fi (2.4 GHz and 5 GHz) for RTMP/RTMPS live streaming directly to major platforms like YouTube, Facebook Live, and more.
Easily configure your stream using a smartphone or tablet, and start broadcasting instantly.
For even more reliable performance, the PXW-Z280 supports USB cellular dongles, ensuring a strong connection in remote locations.
Flexible Interfaces & Pro Audio Options
The PXW-Z280 offers a range of professional connectivity options:
-
Dual SxS memory card slots for simultaneous, relay, or backup recording.
-
Two MI (Multi-Interface) shoes to power compatible accessories such as wireless mics or video lights.
-
Dual XLR audio inputs with independent level controls and support for up to 4-channel audio recording.
This all-in-one design allows you to shoot, record, and stream professional content without the need for external gear.
