| Model |
Spectrum II CMM |
| Type |
Bridge-type Coordinate Measuring Machine |
| Measurement Range |
X: 700–3000 mm (depending on configuration), Y: 600–1500 mm, Z: 500–1000 mm |
| Accuracy |
Up to 1.8 + L/350 µm (depends on size and configuration) |
| Probing System |
Tactile and scanning probe compatible |
| Sensor Options |
VAST XXT, VAST XT, Tactile probes, Optical/Scanning sensors |
| Repeatability |
0.3–1 µm (depending on probing system) |
| Software |
ZEISS CALYPSO metrology software |
| Temperature Compensation |
Integrated temperature sensors for thermal stability |
| Construction |
Granite bridge and base for high stability |
| Drive System |
Precision linear motors with air-bearing guidance |
| Applications |
Automotive, Aerospace, Medical, General Manufacturing |
| User Interface |
Touchscreen control and PC-based operation |
| Optional Features |
Automated part handling, Multi-sensor integration, Extended measurement ranges |
