Description
Gimbal & performance
| Item | Spec |
|---|---|
| Type | Single-hand 3-axis camera stabilizer |
| Tested payload | 4.5 kg (10 lb) |
| Max controlled rotation speed | Pan 360°/s; Tilt 360°/s; Roll 360°/s |
| Mechanical range | Pan 360° continuous; Roll −95° to +240°; Tilt −112° to +214° |
| Operating temperature | −20° to 45° C (−4° to 113° F) |
| Operating frequency | 2.400–2.4835 GHz |
| Bluetooth | 5.1 (Tx power < 8 dBm) |
| Follow/creative modes | PF/TF/FPV, 3D Roll 360, Timelapse/Motionlapse, Panorama, Car-mount calibration |
Dimensions & weight
| Item | Spec |
|---|---|
| Folded (L×W×H) | 271 × 283 × 75 mm (excl. camera, grip, tripod) |
| Unfolded (L×W×H) | 416 × 223 × 202 mm (height incl. grip, excl. tripod) |
| Gimbal weight | ≈ 1242 g |
| Grip weight | ≈ 265 g |
| Extended grip/tripod (metal) | ≈ 226 g |
| Upper + lower quick-release plates | ≈ 110 g |
| Weight (gimbal + grip) | ≈ 1507 g |
Battery (BG30 standard grip)
| Item | Spec |
|---|---|
| Model / type | BG30, LiPo 4S |
| Capacity / energy | 1950 mAh, 30 Wh (15.4 V) |
| Max runtime | Up to 13 hours (balanced, stationary) |
| Charging | ≈ 1.5 h with 24 W fast charging (QC 2.0/PD) |
| Suggested charge temperature | 5° to 40° C |
Optional power (accessory)
| Item | Spec |
|---|---|
| BG70 High-Capacity Battery Grip | Extends runtime to ≈ 29 hours (usage-dependent) |
Ports & expansion
| Item | Spec |
|---|---|
| Accessory interfaces | RSA/NATO ports, 1/4″-20 mount, cold shoe |
| USB-C ports | Video Transmission/LiDAR Range Finder, RSS camera control, Focus Motor, Charging |
| Ecosystem | DJI Focus Pro (follow focus/zoom, LiDAR), DJI Transmission, Ronin SDK accessories |
App, display & languages
| Item | Spec |
|---|---|
| App | DJI Ronin (iOS 11+ / Android 8+) |
| Touchscreen | OLED with screen-lock; multilingual UI (EN/ZN/… ) |
DJI Ronin Image Transmitter (optional)
| Item | Spec |
|---|---|
| Connections | USB-C power/comm, Mini-HDMI, USB-C RSS |
| Frequency | 2.4 GHz / 5.8 GHz |
| Latency / range | ~60 ms / 200 m (FCC/SRRC; 100 m CE) in clear LoS |
| Battery | 2970 mAh; ~3.5 h operation; ~2.5 h charge |
| Size / weight | 82 × 63 × 24 mm / 126 g |
RS Stabilization Algorithm, Fourth Generation
For many use cases, the next-generation RS stabilization algorithm has been thoroughly optimized. It provides outstanding performance and an improved user experience by striking a superior balance between stabilization strength and the tactile feel of camera movement. Furthermore, the RS 4 Pro has much improved stability when shooting vertically, making it simple to learn dynamic shots like low-angle viewpoints or running.
Mount Mode for Cars
Even in shaky conditions, steady capture is made possible by the new Car Mount mode, which adjusts the gimbal stabilization algorithm based on wind resistance and vehicle vibration data.
