Description

Autel EVO Lite 640T Enterprise Standard Bundle Specifications

Category	Specification
Aircraft / Physical	Weight (aircraft): ~866 g
	Folded dimensions: 210 × 123 × 95 mm
	Unfolded dimensions: 433 × 516 × 95 mm
	Maximum rotation speed: 8,000 rpm
	Wheelbase: 368 mm
	Max ascent speed: Slow 3 / Smooth 3 / Standard 5 / Ludicrous 6 m/s
	Max descent speed: Slow 3 / Smooth 2 / Standard 3 / Ludicrous 4 m/s
	Max horizontal flight speed (no wind): Slow 3 / Smooth 5 / Standard 10 / Ludicrous 18 m/s
	Maximum service ceiling: ~2,000 m above sea level
	Max flight altitude (app limit): ~800 m
	Max flight time (no wind): ~40 min
	Max hover time (no wind): ~38 min
	Max flight distance: ~24 km
	Max wind resistance: “Fresh breeze” level
	Maximum tilt angle: Slow 10°, Smooth 30°, Standard 30°, Ludicrous 33°
	Max angular rotation speed (pitch): Smooth 60°/s, Standard 120°/s, Ludicrous 200°/s
	Operating temperature: 0 °C to 40 °C
Sensors / Perception	Visual perception (front/back/down) sensing ranges: front/back 0.5–18 m, downward 0.5–22 m
	Obstacle avoidance effective up to ~12 m/s flight speed
Visible-Light Camera / Gimbal	Sensor: 1 CMOS, 20 MP
	Lens FOV: ~82°, focal length ~29 mm
	Aperture: f/2.8 – f/11
	Focus distance: 0.5 m – ∞
	ISO range (video/photo): 100 – 6,400; night mode up to 48,000
	Shutter speed: 1/8,000 – 8 s (photo); 1/8,000 – 1/30 s (video)
	Zoom: 1–16× digital zoom; “lossless zoom” up to 1.3× (4K) / 3× (1080p)
	Max photo size: 5,472 × 3,076 (16:9) / 3,840 × 2,160
	Video resolution: 3,840 × 2,160 @ 30 fps; 1,920 × 1,080 @ 30 fps
	Video formats / codecs: MP4 / MOV, H.265 / H.264; max bitrate ~120 Mbps
Thermal Imaging Camera	Sensor: Uncooled VOx microbolometer
	Resolution: 640 × 512 pixels
	Lens: 9.1 mm, FOV ~61°, aperture f/1.0
	Sensitivity: ≤ 50 mK @ f/1.0, 25 °C
	Wavelength range: 8 – 14 μm
	Radiometric measurement: center / ROI / rectangle; digital zoom up to 16×
	Temperature range: –20 °C to 150 °C (high gain) / 0 to 550 °C (low gain)
	Accuracy: ±3 °C or ±3% (whichever is greater)
	Max effective measurement distance: 1–25 m
Gimbal (Thermal + Visible)	Mechanical range: Pitch –135° to 45°, Roll –45° to 45°, Yaw –90° to 90°
	Controllable pitch: –90° to 30°
	Stabilization: 3-axis
	Max control speed (pitch): 100°/s
	Angular vibration: ±0.003°
Remote Controller (6-inch Smart Controller)	Material: PC + ABS
	Dimensions (antennas folded): 226.3 × 137.7 × 31.5 mm
	Dimensions (antennas unfolded): 226.3 × 215.4 × 31.5 mm
	Weight: ~607 g
	Operating temperature: –10 °C to 40 °C
	Storage temperature: +15 to +25 °C (1 year), 0 to +30 °C (3 months), –20 to +45 °C (1 month)
	Protection rating: IP43
	Internal storage: 24 GB, supports microSD extension
	OS: Based on Android 6.0.1, supports third-party apps
	USB-C charging: Supports PD / QC fast charging up to 65 W
	USB-A: USB 2.0 port
	GNSS: GPS + Galileo + BeiDou + GLONASS
	Wi-Fi: 802.11a/b/g/n/ac, supports 2×2 MIMO; frequencies 2.4 GHz & 5.8 GHz, EIRP up to 30 dBm
	Bluetooth: 4.2
Image / Transmission System	Transmission frequencies: 2.4 GHz, 5.2 GHz, 5.8 GHz, and 900 MHz (region-dependent)
	Dual-antenna 1T2R detachable design
	Effective transmission distance (no interference): FCC ~10 km, CE ~6 km
Battery (Aircraft)	Type: Li-Po 3S
	Rated capacity: 6,175 mAh
	Energy: 68.7 Wh
	Voltage: 11.13 V
	Charging voltage limit: 12.75 V
	Max charging power: 78 W
	Weight: ~309 g
	Charging temperature range: +5 °C to +45 °C
Battery Storage & Charger	Ideal storage: 22 to 28 °C
	Storage tolerance: –10 to +30 °C, 65% ± 20% RH
	Charger input: 100–240 V AC, 50/60 Hz, 1.5 A
	Charger output: 12.75 V ⎓ 5 A; USB-A: 5 V ⎓ 3 A / 9 V ⎓ 2 A / 12 V ⎓ 1.5 A
Other Features & Capabilities	AI target recognition: people, vehicles, boats, etc.
	Split-screen mode: visible / thermal / map simultaneously
	Offline map support
	Data privacy & encryption: AES encryption for media & flight logs, user consent for uploads
	Live streaming: RTMP & GB28181 protocol support (pending updates)

Powerful Dual-Camera Drone for Industrial and Professional Missions

The Autel EVO Lite 640T Enterprise Standard Bundle redefines professional aerial imaging with its advanced dual-camera system combining thermal and visible-light sensors. Designed for enterprise users, first responders, inspection teams, and mapping professionals, this compact yet powerful drone delivers precision, reliability, and versatility in every flight.

With a 640×512 thermal camera and a high-resolution visible-light camera, the EVO Lite 640T Enterprise lets you see beyond the visible spectrum — capturing temperature data, spotting heat signatures, and identifying anomalies instantly. Its radiometric thermal imaging provides accurate temperature readings across objects and environments, making it a top-tier choice for search and rescue, infrastructure inspection, firefighting, and security monitoring.

Next-Level Aerial Performance

The EVO Lite 640T is built to perform in demanding environments. With up to 40 minutes of flight time, a 12 km transmission range, and a fresh breeze-level wind resistance, you can cover large areas efficiently with consistent performance. Its three-directional obstacle avoidance system ensures flight safety, while AI-powered target recognition helps identify and track people, vehicles, or objects automatically.

Fly confidently in any scenario with precise controls, a smooth flight experience, and intelligent flight modes that make complex missions easy and safe to complete.

Intelligent Dual-Gimbal System

Equipped with a visible 20MP camera and a 640×512 thermal camera, the EVO Lite 640T captures every detail with precision. You can view thermal and RGB feeds side-by-side using split-screen mode, enabling you to detect hidden issues and make better decisions in real time.

Whether you’re capturing visual inspections, mapping high-temperature zones, or identifying heat leaks, the EVO Lite 640T’s radiometric thermal imaging ensures unmatched accuracy and detail.

Smart Controller with 6-Inch Display

The included 6-inch Smart Controller enhances operational efficiency with its ultra-bright, anti-glare screen that delivers crystal-clear visuals even under direct sunlight. Built on an Android platform, it supports third-party apps, fast-charging via USB-C, and offline map support. With an IP43 protection rating, it’s designed for field use in rugged environments.

The ergonomic design ensures comfortable handling during long operations, while the customizable interface allows you to tailor your workflow exactly to your mission needs.

Strong Connectivity & Secure Data

The EVO Lite 640T’s dual-antenna 1T2R design and multi-frequency transmission system provide stable, interference-free communication even in complex environments. Its AES data encryption safeguards your mission data, ensuring complete privacy and security during operations.

You can also livestream your missions using RTMP or GB28181 protocols, keeping teams connected and informed in real time.

Long-Lasting Power and Efficiency

Powered by a 6,175 mAh Li-Po 3S intelligent battery, the EVO Lite 640T delivers up to 40 minutes of flight time per charge. The high-efficiency power system supports quick charging up to 78W, helping you stay airborne longer and spend less time on the ground.

Whether you’re capturing critical data or responding to an emergency, this drone ensures reliable power and endurance every time.

Built for Enterprise-Grade Reliability

The Autel EVO Lite 640T is compact, portable, and ready to deploy in seconds. Despite its lightweight frame, it offers exceptional durability and balance, handling professional workloads with ease. From infrastructure inspections to law enforcement surveillance, search-and-rescue missions, or environmental monitoring, it’s engineered for accuracy, safety, and dependability.

Why Choose Autel EVO Lite 640T Enterprise?

When precision, clarity, and dependability matter, the Autel EVO Lite 640T Enterprise stands out as one of the most capable drones in its class. Its blend of advanced imaging, intelligent features, and long flight performance makes it the perfect choice for industrial, public safety, and inspection professionals who demand excellence in every mission.
