A40TR-35 AI Object Tracking Target GPS Coordinate Calculation and LRF Gimbal Camera

High-performance tri-sensor UAV gimbal with EO, IR, and integrated laser rangefinder
Equipped with a 40× optical zoom daylight camera for ultra-clear long-range imaging
Advanced 35mm thermal lens providing superior detection range and clarity
Supports precise distance measurement through built-in laser rangefinder
3-axis stabilized gimbal for smooth, vibration-free aerial footage
AI functions including auto-tracking, intelligent recognition, and smart zoom
Ideal for defense surveillance, search & rescue, border patrol, and industrial inspection
Compact, rugged, and compatible with a wide variety of enterprise drones

Description

Category	Specifications
Model	A40TR-35
Gimbal Type	3-axis stabilized UAV gimbal
EO Camera Sensor	1/2.8″ CMOS sensor
EO Video Resolution	1080p Full HD
Optical Zoom	40×
Digital Zoom	Up to 16×
Thermal Sensor	Uncooled IR thermal imaging module
Thermal Resolution	640 × 512 (varies by version)
Thermal Lens	35mm long-range thermal lens
Thermal Detection Range	Extended long-distance detection capability
Laser Rangefinder	Integrated
LRF Range	Up to 1,500 m (approx., model dependent)
Gimbal Stabilization	3-axis (Pitch, Roll, Yaw)
Pitch Range	–90° to +30°
Yaw Rotation	360° continuous
Stabilization Accuracy	±0.02°
AI Features	Auto-tracking, target recognition, intelligent zoom
Video Output	HDMI / Digital signal output
Control Protocols	PWM, S.BUS, Serial
Power Input	12V DC
Operating Temperature	–10°C to +55°C
Weight	Around 1,000–1,200g depending on configuration
Applications	Defense surveillance, SAR, border monitoring, inspection missions
