Experience true HD FPV footage with the DJI Goggles 3. Now, featuring pass-through cameras and a convenient flip-up hinge, you can enjoy even greater flexibility.

Regarding video transmission:

• To begin with, the Video Transmission System is O4.

• Moreover, the Live View Quality offers 1080p@30/50/60/100fps for crystal-clear visuals.

• Additionally, the Operating Frequency includes:

  • 2.400–2.4835 GHz

  • 5.170–5.250 GHz*

  • 5.725–5.850 GHz*

• Furthermore, the Transmitter Power (EIRP) specifications are:

  • 2.4 GHz ＜33 dBm (FCC) ＜20 dBm (CE/SRRC/MIC)

  • 5.1 GHz < 23 dBm (CE)

  • 5.8 GHz ＜33 dBm (FCC) ＜30 dBm (SRRC) < 14 dBm (CE)

• In terms of Communication Bandwidth, it can reach a maximum of 60 MHz.

• When considering transmission distances (unobstructed, free of interference):

  • FCC: 13 km (subject to the aircraft’s max flight distance)

  • CE: 10 km

  • SRRC: 10 km

  • MIC: 10 km

• However, under conditions of unobstructed areas with interference:

  • Strong Interference: Urban landscapes, approx. 1.5–4 km

  • Medium Interference: Suburban landscapes, approx. 4–10 km

  • Low Interference: Suburb/seaside areas, approx. 10–13 km

• Conversely, under obstructed conditions with low interference:

  • Obstructed by Buildings: approx. 0–0.5 km

  • Obstructed by Trees: approx. 0.5–3 km

• For downloads, the Max Download Speed via Wi-Fi is 30 MB/s.

• Moreover, the Lowest Latency with DJI Goggles 3 is:

  • 1080p/100fps: 24 ms

  • 1080p/60fps: 40 ms

• Lastly, the Max Video Bitrate is 60 Mbps, and it uses 4 antennas, configured as 2T4R for superior signal strength.

• Starting with the Takeoff Weight, it is approximately 13.29 oz (377g).

• When it comes to Max Ascent Speed, it reaches 6 m/s in Normal mode and 9 m/s in Sport mode.

• Similarly, the Max Descent Speed is 6 m/s in Normal mode and 9 m/s in Sport mode.

• Meanwhile, the Max Horizontal Speed (near sea level, no wind) is:

  • 8 m/s (Normal mode)

  • 16 m/s (Sport mode)

  • 27 m/s (Manual mode)

• Moreover, the Max Takeoff Altitude is an impressive 5000m.

• Regarding Max Flight Time, it offers approximately 23 minutes of airborne operation.

• Additionally, the Max Hovering Time stands at around 21 minutes.

• For distance, the Max Flight Distance reaches up to 13.0 km.

• In terms of Max Wind Speed Resistance, it can handle up to 10.7 m/s (Level 5).

• Considering environmental conditions, the Operating Temperature ranges from 14°F to 104°F (-10°C to 40°C).

• Furthermore, it uses a Global Navigation Satellite System supporting GPS + Galileo + BeiDou.

• Looking at Hovering Accuracy Range:

  • Vertical: +/-0.1 m (with vision positioning), +/-0.5 m (with GNSS positioning)

  • Horizontal: +/-0.3 m (with vision positioning), +/-1.5 m (with GNSS positioning)

• As for Internal Storage, it boasts a built-in 46GB capacity.

• Finally, the overall Dimensions (L x W x H) are 7.28 x 8.34 x 2.51 inches (185 x 212 x 64 mm).

• • • Starting with the Image Sensor, it features a 1/1.3″ image sensor with effective pixels of 12 MP.

    • Moving to the Lens specifications, it offers a FOV of 155 degrees, a format equivalent of 12 mm, an aperture of f/2.8, and a focus range from 0.6 m to infinity.

    • In terms of ISO Range, it supports 100-25600 both in Auto and Manual modes.

    • Regarding Shutter Speed, it offers 1/8000-1/30 s for video and 1/8000-1/50 s for photo capture.

    • For Max Image Size, it delivers 4000 x 2256 (16:9) and 4000 x 3000 (4:3) resolutions.

    • When considering Still Photography Mode, it supports single-shot photography.

    • As for Photo Format, it uses JPEG format for saving images.

    • Looking at Video Resolution options, it supports:

      • 4K (4:3): 3840 x 2880@30/50/60fps

      • 4K (16:9): 3840 x 2160@30/50/60fps

      • 2.7K (4:3): 2688 x 2016@30/50/60fps

      • 2.7K (16:9): 2688 x 1512@30/50/120fps

      • 1080p (4:3): 1440 x 1080@30/50/120fps

      • 1080p (16:9): 1920 x 1080@30/50/120fps

    • Additionally, the Video Format is MP4 (H.264/H.265).

    • In terms of Max Video Bitrate, it reaches up to 130 Mbps.

    • Moreover, the Supported File System is exFAT.

    • Considering Color Modes, it offers Standard and D-Log M profiles for flexible editing.

    • Exploring further, the Camera FOV supports normal mode, wide-angle mode, and ultra-wide-angle mode.

    • Finally, Electronic Image Stabilization (EIS) supports RockSteady 3.0+ and HorizonSteady, both of which can be disabled if needed.

• To begin with, Stabilization is handled by a single-axis mechanical gimbal focused on tilt functionality.
• Moving on to the Mechanical Range, it supports a tilt movement from -95° to 90°, offering wide coverage.
• In terms of Controllable Range, tilt can be adjusted between -85° to 80° for precise framing.
• Regarding Max Control Speed, the gimbal can tilt at up to 100° per second, ensuring responsive adjustments.
• When considering Angular Vibration Range, it maintains a minimal vibration of ±0.01°, delivering smooth footage.
• Finally, for the Electronic Roll Axis, real-time screen correction is unavailable during recording, although it can be applied to the footage afterward on the drone.

• Starting with Sensing Type, the system uses downward and backward visual positioning for enhanced flight stability.
• Focusing on the Downward sensing, it features a ToF Effective Measurement Height of up to 10 meters.
• In addition to that, the Precise Hovering Range spans from 0.3 to 10 meters for accurate low-altitude control.
• Moreover, the Measurement Range extends from 0.3 to 20 meters, providing reliable ground detection.
• As for the Field of View (FOV) downward, it covers 78° horizontally and 78° vertically.
• Turning to the Backward sensing, it offers a Measurement Range between 0.5 and 20 meters.
• Similarly, the Backward FOV is also 78° horizontally and 78° vertically, ensuring wide obstacle detection.
• Finally, for the Operating Environment, the sensors work best over diffuse reflective surfaces with discernible patterns and require adequate lighting conditions (lux > 15, like typical indoor lighting).



• To begin with, the Video Transmission System utilizes DJI’s advanced O4 technology, offering enhanced performance and stability.
• Furthermore, the Live View Quality supports resolutions of 1080p at 30/50/60/100fps, ensuring crystal-clear real-time visuals.
• Regarding the Operating Frequency, it works across multiple bands:
  • 2.400–2.4835 GHz
  • 5.170–5.250 GHz
  • 5.725–5.850 GHz
• In terms of Transmitter Power (EIRP):
  • 2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
  • 5.1 GHz: <23 dBm (CE)
  • 5.8 GHz: <33 dBm (FCC), <30 dBm (SRRC), <14 dBm (CE)
• Additionally, the Communication Bandwidth can reach up to 60 MHz, facilitating robust data flow.
• When it comes to Maximum Transmission Distance (unobstructed and interference-free):
  • FCC: 13 km (limited by aircraft’s max flight range)
  • CE / SRRC / MIC: 10 km each
• Meanwhile, under unobstructed but interference-prone conditions:
  • Strong Interference (urban): approx. 1.5–4 km
  • Medium Interference (suburban): approx. 4–10 km
  • Low Interference (suburb/seaside): approx. 10–13 km
• Continuing with obstructed environments and low interference:
  • Obstructed by Buildings: approx. 0–0.5 km
  • Obstructed by Trees: approx. 0.5–3 km
• In terms of Download Speed via Wi-Fi, it reaches up to 30 MB/s under ideal conditions.
• For latency performance with DJI Goggles 3:
  • 1080p/100fps: 24 ms
  • 1080p/60fps: 40 ms
• Lastly, the system supports a Max Video Bitrate of 60 Mbps and features 4 antennas (2T4R) for improved transmission stability.



• To begin with, the system supports standard wireless communication with Wi-Fi Protocol 802.11a/b/g/n/ac, ensuring compatibility with a wide range of devices.
• Additionally, it operates over two main frequency bands for flexible connectivity:
  • 2.400–2.4835 GHz
  • 5.725–5.850 GHz
• In terms of Transmitter Power (EIRP):
  • At 2.4 GHz:
    • Less than 20 dBm (FCC/CE/SRRC/MIC)
  • At 5.8 GHz:
    • Less than 20 dBm (FCC/SRRC)
    • Less than 14 dBm (CE)

• To start, the system features Bluetooth 5.0 protocol, offering improved range, speed, and connectivity over previous versions.
• Moreover, it operates within the 2.400–2.4835 GHz frequency range, ensuring compatibility across a broad spectrum of Bluetooth-enabled devices.
• Finally, the transmitter power (EIRP) is rated at less than 10 dBm, promoting efficient energy use while maintaining strong signal performance.

Recommended Charger:

DJI 65W Portable Charger
DJI 65W Car Charger
USB Power Delivery charger

Recommended microSD Cards:

SanDisk Extreme PRO 32GB U3 A1 V30 microSDHC
Lexar Professional 1066x 64GB U3 A2 V30 microSDXC
Lexar Professional 1066x 128GB U3 A2 V30 microSDXC
Lexar Professional 1066x 256GB U3 A2 V30 microSDXC
Lexar Professional 1066x 512GB U3 A2 V30 microSDXC
Kingston CANVAS Go! Plus 64GB U3 A2 V30 microSDXC

Recommended microSD Cards (Contd.):

Kingston CANVAS Go! Plus 128GB U3 A2 V30 microSDXC
Kingston CANVAS React Plus 64GB U3 A1 V90 microSDXC
Kingston CANVAS React Plus 128GB U3 A1 V90 microSDXC
Kingston CANVAS React Plus 256GB U3 A1 V90 microSDXC
Samsung EVO Plus 512GB U3 A2 V30 microSDXC

• • • To begin with, the battery has a capacity of 2150 mAh, providing ample power for extended flight sessions.

    • In terms of voltage, it operates at a standard 14.76 V, with a maximum charging voltage of 17 V for optimal performance.

    • Additionally, it delivers an energy output of 31.7 Wh@0.5C, balancing power and efficiency effectively.

    • When it comes to temperature, charging is supported between 41°F to 104°F (5°C to 40°C), ensuring safe operation in varied climates.

    • For faster charging, using the Charging Hub (60W max) results in:

      • 0 to 100% in approximately 45 minutes

      • 10 to 90% in about 30 minutes

    • On the other hand, when charging directly via the drone (30W max):

      • 0 to 100% takes around 88 minutes

      • 10 to 90% takes approximately 60 minutes

    • Moreover, the battery is required and included in the package.

    • In terms of composition, it features a lithium-ion material and is classified as non-universal.

    • Lastly, the battery weighs around 5.11 oz (145 g), making it both lightweight and efficient.
