| Model |
QIR50T Pro |
| Thermal Sensor Resolution |
640 × 512 (High-resolution thermal core) |
| Thermal Lens Options |
25mm / 35mm / 50mm (varies by variant) |
| Visible Camera |
1080p HD / 4MP visible light camera |
| Gimbal Type |
3-axis stabilized gimbal |
| Detection Range |
Up to 1500–2000m (depending on lens) |
| Temperature Measurement Range |
–20°C to +550°C |
| Accuracy |
±2°C or ±2% of reading |
| Frame Rate (Thermal) |
25Hz / 30Hz |
| Color Palettes |
White-Hot, Black-Hot, Iron-Red, Rainbow, Arctic, Fusion |
| Image/Video Output |
HDMI / SD card recording |
| Real-Time Features |
Spot, line, and area temperature analysis |
| Connectivity |
Standard drone gimbal port / power supply port |
| Housing Material |
Aerospace-grade aluminum alloy |
| Protection Rating |
IP54 / IP66 (varies by unit) |
| Weight |
Approx. 350g – 420g |
| Power Consumption |
7W – 10W |
| Operating Temperature |
–10°C to +50°C |
