DJI M300 Drone Air Payload

Drop Release Hook Mechanism System

Support up to 5 payloads at once with a 5-hook design, allowing you to mount and release multiple items in a single flight.

Additionally, you can safely carry up to 10kg total payload weight, though we recommend keeping it under 3kg for optimal DJI M300 performance.
The system integrates seamlessly with the DJI M300 and is developed using the DJI Onboard SDK for full compatibility.
You can control each hook individually via the DJI Smart Controller using the DJI Pilot app, making payload drops precise and efficient.
Moreover, the quick-release mechanism lets you install and remove the system easily, saving time during mission prep.

Description

Introducing the DJI M300 Drone Air Payload Drop Release Hook Mechanism System

Use the DJI M300 Air Drop Release Mechanism to carry and drop payloads with precision, fully developed on the DJI Onboard SDK.
Easily control and operate the drop function through the DJI Smart Controller using the DJI Pilot app.
Additionally, the 5-hook design lets you carry up to 5 separate payloads in a single mission, improving operational efficiency.
Although the system supports over 10kg payload, we recommend limiting it to 3kg for stable performance with the DJI Matrice 300 RTK.
Moreover, the quick-release design allows fast installation and removal, saving time during mission prep.
Built with aviation-grade aluminum and carbon fiber, it stays lightweight while handling heavy loads.
For added versatility, you can also choose the non-DJI SDK version, which works with any multi-rotor drone and operates via PWM control.

For more information , watch this video

Specifications

Specification	Details
Size	62mm × 62mm × 92mm
Weight	295g
Interface	DJI Onboard SDK
Power Consumption	18W
Operating Voltage	5V
Control Method	DJI Pilot via DJI Smart Controller
Control Range	As far as the DJI M300 drone flight range
Installation	Quick-release
Number of Hooks	5
Max Payload Weight	10kg (recommended ≤ 3kg for DJI M300 performance)
Support for Non-DJI Drones	Yes – Non-DJI SDK version available, compatible via PWM control

1. How do I control the drop mechanism during flight?
You can easily control the drop and release using the DJI Smart Controller via the DJI Pilot app, allowing real-time operation and precision.

2. How many payloads can I carry at once?
Thanks to the 5-hook design, you can mount and release up to 5 different payloads in a single flight, boosting efficiency for complex missions.

3. What is the maximum payload weight I can carry?
Although the mechanism supports over 10kg, we recommend keeping the payload under 3kg for stable and safe operation with the DJI M300.

4. Can I install the drop mechanism quickly?
Yes, the quick-release design lets you install or remove it in seconds, making it convenient for fast mission turnaround.

5. Can I use this system with non-DJI drones?
Absolutely! The non-DJI SDK version is available, and you can operate it via PWM control on any compatible multi-rotor drone.
