Dobot Nova-5
dobot-nova-5_
Dobot Nova 5
Nova 5 by Dobot
Dobot Nova 5

Dobot Nova 5

• 6-axis collaborative robot with 5 kg payload and 850 mm reach for medium-complexity automation
• IP54 dust and splash resistant — built for real production floor conditions
• Maximum TCP speed of 2 m/s — one of the fastest in the 5 kg collaborative robot class
• Multi-protocol connectivity: Wi-Fi, TCP/IP (2× WAN), Modbus TCP, and Modbus RTU (RS485)
• Aluminium alloy and ABS plastic construction — strong, lightweight at 14 kg
• ±0.05 mm repeatability for consistent, accurate placement across extended production runs
• Typical power consumption of 230W for high-performance multi-shift operation

Price on request
  • Trusted dealerDirect manufacturer partnership
  • Pan-India deliveryInsured shipping, all states
  • Post-sale supportTraining + service included
Overview

What makes it work

Dobot Nova 5 Collaborative Robot – 5 kg Payload, 850 mm Reach | xBoom.in

Collaborative Robot · IP54 · High Payload

Dobot Nova 5
Collaborative Robot

A 5 kg payload, 850 mm reach collaborative robot with IP54 protection and multi-protocol connectivity — built for demanding light-to-medium industrial automation.

5kg
Payload
850mm
Reach
2m/s
Max TCP Speed
IP54
Protection
5kg
Payload
850mm
Reach
2m/s
Max TCP Speed
±0.05mm
Repeatability
IP54
IP Rating
14kg
Weight

Overview

More Payload. More Reach. Same Collaborative Design.

The Dobot Nova 5 steps up where the Nova 2 ends — doubling the payload to 5 kg and extending reach to 850 mm, while retaining the same IP54 rating, multi-protocol connectivity, and aluminium alloy construction. It is designed for manufacturers who need a cobot that can handle heavier parts across a wider work envelope without requiring a full industrial robot setup.

At 14 kg and with a maximum TCP speed of 2 m/s, the Nova 5 brings genuine production-floor performance to collaborative applications — from welding support and bin picking to loading, dispensing, and assembly tasks where heavier components are involved.

Key Features

Industrial Payload. Collaborative Safety.

💪
5 kg Payload Capacity
With a 5 kg (11 lbs) rated payload, the Nova 5 handles heavier workpieces that are out of reach for smaller cobots — ideal for medium-weight part handling, palletising, and tool use.
📐
850 mm Working Radius
An 850 mm reach (33.5 in) covers a wide work envelope, enabling the Nova 5 to service larger workstations and reach across conveyor widths without repositioning the base.
🚀
2 m/s Maximum TCP Speed
The Nova 5 reaches a top speed of 2 m/s (78.7 in/s) at the tool centre point, making it one of the faster cobots in its payload class for high-cycle-rate automation tasks.
🛡️
IP54 Dust & Splash Rated
The IP54 rating ensures the Nova 5 functions reliably in environments where dust, coolant mist, or light liquids are present — common in machining, food processing, and assembly lines.
🌐
Multi-Protocol Communication
Connects via 2× WAN (TCP/IP, Modbus TCP), 1× RS485 (Modbus RTU), and Wi-Fi — compatible with modern PLCs, SCADA systems, and wireless factory networks.
⚡
230W Typical Power
Operating at a typical 230W, the Nova 5 delivers strong performance without excessive energy demands — practical for continuous multi-shift production.

Comparison

Nova 2 vs Nova 5 — Which is Right for You?

SpecificationNova 2Nova 5
Payload2 kg5 kg
Reach625 mm850 mm
Max TCP Speed1.6 m/s2 m/s
Repeatability±0.05 mm±0.05 mm
IP RatingIP54IP54
Weight11 kg14 kg
Typical Power100 W230 W
CommunicationTCP/IP, Modbus TCP, RTU, Wi-FiTCP/IP, Modbus TCP, RTU, Wi-Fi

Specifications

Technical Specifications

SpecificationDetails
Weight14 kg
Payload5 kg (11 lbs)
Reach850 mm (33.5 in)
Maximum Speed of TCP2 m/s (78.7 in/s)
Repeatability±0.05 mm
IP RatingIP54
Typical Power Consumption230 W
Communication2× WAN (TCP/IP, Modbus TCP); 1× RS485 (Modbus RTU); Wi-Fi
MaterialAluminium alloy, ABS plastic

A+ Content

The Nova 5 in Production

Payload & Reach

When 2 kg Isn't Enough

Many light-industry automation tasks involve components that exceed the capability of a 2 kg cobot. Automotive sub-assemblies, metal brackets, heavier consumer electronics modules, and packaged food items all push beyond what the Nova 2 can handle. The Nova 5 bridges the gap — providing 5 kg capacity and 850 mm of reach while keeping the same IP54 protection and collaborative operating profile.

Speed

2 m/s. Built for High-Frequency Cycles.

At a maximum TCP speed of 2 m/s — faster than most collaborative robots in the 5 kg class — the Nova 5 doesn't sacrifice throughput for safety. Whether it's rapid loading and unloading of a CNC machine, high-speed pick-and-place on a packaging line, or repetitive quality checks, the Nova 5 maintains pace with the production rhythm.

Applications

Where the Nova 5 Performs Best

🏭
CNC Loading/Unloading
📦
Palletising
🔩
Assembly
🔍
Quality Inspection
💧
Gluing & Dispensing
🚚
Part Transfer

Dobot Nova 5 Collaborative Robot in India

The Dobot Nova 5 is available in India through xBoom.in, an authorised Dobot reseller. We serve manufacturing businesses in Bangalore, Mumbai, Pune, Chennai, Hyderabad, Delhi NCR, and beyond. Contact us for pricing, technical consultation, and on-site demonstration.

Is the Nova 5 suitable for my industry?

The Nova 5 is used across automotive, food & beverage, consumer electronics, healthcare, metal processing, and semiconductor industries. Its IP54 rating, 5 kg payload, and multi-protocol communication make it one of the most versatile entry-to-mid-range collaborative robots available in India.

See It In Action

Dobot Nova 5 Videos

Dobot Nova 5 – Official Product Video

Official Dobot product video for the Nova Series collaborative robots

Dobot Nova Series – Official Launch

Nova 5 and Nova 2 launch for commercial automation in retail, catering and healthcare

Dobot Nova 5 – Cobot Testing & Demo

6-axis Nova 5 cobot testing and real-world application demonstration

FAQ

Frequently Asked Questions

The Nova 5 has a maximum payload of 5 kg (11 lbs), making it suitable for heavier part handling, CNC tending, and palletising tasks that exceed the capability of smaller cobots.
The Nova 5 offers 2.5× more payload (5 kg vs 2 kg), a larger reach (850 mm vs 625 mm), and a higher maximum TCP speed (2 m/s vs 1.6 m/s). Both share the same IP54 rating, materials, and communication protocols.
The Nova 5 supports TCP/IP and Modbus TCP via 2× WAN ports, Modbus RTU via 1× RS485, and Wi-Fi — providing full flexibility for integration into any factory network.
Yes. The Nova 5 is IP54 rated, providing protection against dust ingress and low-pressure water splashing, making it appropriate for real manufacturing environments including machining and food production areas.
The Nova 5 offers ±0.05 mm position repeatability, ensuring consistent and accurate placement across thousands of operating cycles.
xBoom.in is an authorised Dobot reseller in India. Contact us via WhatsApp at wa.aisensy.com/xboom or through our website for pricing, demos, and deployment support.
