VT15E Electric Compound Wing
- 2600mm wingspan, 1500mm length, 600mm height
- Frame weight: 4.7kg | Max takeoff weight: 15kg
- Max payload capacity: 2.5kg
- Endurance: 210 minutes @ 1.5kg payload
- Cruise speed 70–90km/h, max speed 100km/h
- Rotor climb ≤3.5m/s, descent ≤1.5m/s
- Service ceiling: 5000m
- Operating range: -10°C to 45°C
- Trusted dealerDirect manufacturer partnership
- Pan-India deliveryInsured shipping, all states
- Post-sale supportTraining + service included
What makes it work
VT15E
Electric Compound Wing VTOL UAV
The VT15E is a electric compound wing vtol uav configured for fixed-wing efficiency with vertical takeoff and landing convenience, built for long-endurance mapping, surveillance and inspection missions.
Wingspan 2600mmMTOW 15kgMax Payload 2.5kgEndurance 210min @ 1.5kgWind Resistance Level 6IP54
15kg
Max Takeoff Weight2.5kg
Max Payload210min @ 1.5kg
Endurance100km/h
Max SpeedProduct Overview
Full Specifications
| Wingspan | 2600mm |
| Length | 1500mm |
| Height | 600mm |
| Frame Weight | 4.7kg |
| Max Takeoff Weight | 15kg |
| Max Payload | 2.5kg |
| Endurance | 210min @ 1.5kg |
| Cruise Speed | 70–90km/h |
| Max Speed | 100km/h |
| Rotor Climb Rate | ≤3.5m/s |
| Rotor Descent Rate | ≤1.5m/s |
| Service Ceiling | 5000m |
| Operating Temperature | -10°C ~ 45°C |
| Wind Resistance | Level 6 |
| Protection Rating | IP54 |
| Packing Dimensions | 1530×430×585mm |
Good to Know
Frequently Asked Questions
What is the VT15E's maximum takeoff weight and payload?
The VT15E has a maximum takeoff weight of 15kg and a maximum payload capacity of 2.5kg.
How long can the VT15E stay airborne?
Endurance is rated at 210min @ 1.5kg, with a cruise speed of 70–90km/h and a maximum speed of 100km/h.
What is the operating envelope for the VT15E?
Service ceiling is 5000m, with an operating temperature range of -10°C ~ 45°C and wind resistance up to Level 6.
Is the VT15E rated for outdoor / field use?
Yes. The airframe carries an IP54 ingress protection rating, suited to routine outdoor field operations.
What are the packed shipping dimensions?
Packing dimensions: 1530×430×585mm.
